Jig List
JGF-10101-01
Jig List
SHEET
8/9
No. Jig name / Parts No. Outside appearance Qty Uses Remarks
42 Thickness gauge
1 Calibration
43 U-nut wrench
2-515-522-01
1 Tightening of feed U-nut
44 Nozzle changing jig kit (option)
A-8417-461-A
1 Adjustment of nozzle change assembly
45 Part Abandonment conveyor jig
(OPTION)
A-8417-472-A
1 Part Abandonment conveyor setup Pin gauge : 4-722-336-01
Shaft : 4-722-335-01
46 Y axis bearing draw-out jig
2-186-544-01
1 Removal of Y axis ball bearing
47 Y axis bearing fixing jig
2-186-546-01
1 For fixing Y axis bearing
48 Y axis bearing support jig
2-186-545-01
1 Installation of Y axis ball bearing
Jig List
JGF-10101-01
Jig List
SHEET
9/9
No. Jig name / Parts No. Outside appearance Qty Uses Remarks
49 Y axis ball screw clamp
1 Y axis ball screw clamp Lever: 2-186-547-01
Block: 2-186-548-01
50 Bearing puller
1 Ball screw bearing removal
51 RN belt tension jig
2-515-562-01
1 Adjustment of RN-axis belt tension
52 A-head assembly stand
A-8417-186-A
1 A-head assembling Assembling plate for F130: 2-186-543-01
53 Jig box and case (1 set)
1
