Chapter 6: Operation
Contents
Quick Start: Running a Job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Preparing to Run a Pre-programmed Job . . . . . . . . . . . . . . . . . . . . . . . .6-4
Power up the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Home Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Setup the Manual Tube Input Device (MTID). . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Setup the Taper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Select Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Setup the Pick Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Setup Vision. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Run the Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Downloaded from www.Manualslib.com manuals search engine
6-2 TM-401 User’s Guide
Quick Start: Running a Job D292104.8a.fm
Quick Start: Running a Job
The following is an outline of the basic steps required to run a pre-programmed job. More
detailed instructions follow in the next section of this chapter.
Caution: Users should always wear protective eye wear when operat-
ing or maintaining the TM-401.
1. Power up.
• Power up the machine by turning on the Main Power Switch.
• Press the Reset button.
2. Home the motors.
• Open the Run Tab on the HMI and select Home Motors.
3. Setup Manual Tube Input Device (MTID).
• Ensure the correct tooling is installed on the MTID for the components that will
be processed.
• Load components.
• Turn Vibratory ON.
• Adjust Amplitude and Frequency for proper feeding.
4. Setup Taper.
• Ensure sufficient carrier tape and cover tape are loaded to complete the job.
• Load an empty take-up reel.
• Run peel force test to verify seal.
5. Setup the Pick Head.
• Ensure the correct nozzle is installed for the part that will be picked.
• Observe the vacuum sensor, adjusting nozzle pressure as necessary.
• Adjust Blow-off Pressure as needed to achieve proper part placement.
• Close the enclosure doors.
Quick
Start
Downloaded from www.Manualslib.com manuals search engine
D292104.8a.fm Quick Start: Running a Job
Chapter 6: Operation 6- 3
6. Select Job.
• Open the Job Tab on the HMI. Select the desired job from the Job Library and
press Open to open the selected job in the Run Tab.
7. Setup Vision.
• Open the Taper Tab on the HMI and advance to the second screen.
• Ensure camera is enabled. Configure inspection as needed.
Note: To configure vision inspection, see Chapter 4: Setup.
8. Run the Job.
• On the HMI, select the Run Tab then press Run.
• Load/unload parts and reels as needed.
Caution!
V-TEK® Incorporated takes no responsibility for the safety of TM-401 if it is
used for any purpose other than the intended purpose as specified in this
User’s Guide.
Quick
Start
