4OM-1603
2-5
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
010904
Feederbaseconrm(Front)
Disconnect elevator unit (front).
Check connector.
010905
Feederbaseconrm(Front)
Feeder cart (front) is not upper position.
Push feeder ready sw.
010906
Feederbaseconrm(Front)
Push feeder ready sw.
010907
Feederbaseconrm(Front)
Feeder base power or Feeder power is "OFF". Please press "Feeder Ready"
switch(Front), and put it up again after putting Feeder Cart(Front) down.
011001
Empty Feeder (rear)
Please set the feeder (rear) that used by the pattern program.
011101
Empty Feeder (front)
Please set the feeder (front) that used by the pattern program.
010b01
Feeder is not ready (rear)
Please turn on the Feeder Ready SW (rear).
010c01
Feeder is not ready (front)
Please turn on the Feeder Ready SW (front).
010d01
Pattern program is abnormal
Please set the normal pattern program
010e01
Prod Chng is not ready
Conveyorwidthdoesnottproductiondata.
Execute conveyor width setup.
011401
Zeroingnotnish
Perform All zeroing
011402
Zeroingnotnish
Perform All zeroing
011403
Zeroingnotnish
Perform All zeroing
011404
Zeroingnotnish
Perform All zeroing
011405
Zeroingnotnish
Perform All zeroing
011406
Motor is not servo on
Perform All zeroing
011701
P.C.B. position
Please position the P.C.B.
011702
P.C.B. position
Set the P.C.B. lower side position.
011703
P.C.B. position
Set the P.C.B. upper side position.
011704
P.C.B. position
Execute P.C.B. position cancel after cancelling operation.
011705
P.C.B. position
Please position P.C.B. [Input or Output] of [Lane A]
1012-005
4OM-1603
2-6
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
011706
P.C.B. position
Please position P.C.B. [Output position] of [Lane A].
011707
P.C.B. position
Please position P.C.B. [Input position] of [Lane A].
011708
P.C.B. position
Please position P.C.B. [Input or Output] of [Lane B].
011709
P.C.B. position
Please position P.C.B. [Output position] of [Lane B].
01170a
P.C.B. position
Please position P.C.B. [Input position] of [Lane B].
011a01
Nozzlestockerlowerlimitconrmation
Please perform All zeroing.
011c01
Nozzlearrangementconrmation
The nozzle arrangement of the Current Program and the head is different.
012a01
Tray shortage Comp (rear)
Please supply comp, close tray door(rear) and push tray ready SW(Rear).
012b01
Tray shortage Comp (front)
Please supply comp, close tray safety door and push tray ready SW(Front).
013101
Feeder set Err
A pickup miss comp is detected. (Rear)
013102
Feeder set Err
The feeder latch worked off. (Rear)
013103 Feeder set Err
A pickup miss comp is detected. (Front)
013104 Feeder set Err
The feeder latch worked off. (Front)
013105 Feeder set Err
Not connect selected feeder.
013b01 Feeder Ready SW
Please wait stage ready on
013c01 Stage Ready SW
Please wait feeder ready on
013c02 Stage Ready SW
Do not open safety cover while line sensor program updating.
014101 Operation Parameter
Test mode of transfer set ""Disable"" in pass mode.
Check setting.
014102 Operation Parameter
-----
014103 Operation Parameter
-----
014201 Device System Setup
Please set Input Machine Output Mode [SMEMA Mode].
014202 Device System Setup
Please set Output Machine Output Mode [SMEMA Mode].
1012-005
4OM-1603
2-7
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
014b01 Nozzle Placement Data Check
Set the nozzle ID to use for the No.1 nozzle placement data.
015001 Nozzle Location Check
Notfoundttingnozzleforcalibration.(Rear)
Set type "HA09A" nozzle on Head 1 Nozzle 1.
015002
Nozzle Location Check
"Notfoundttingnozzleforcalibration.(Front)
Set type "HA09A" nozzle on Head 2 Nozzle 1.
015003
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Rear)
Set type "HA09A" nozzle on Head 1 Nozzle 1.
015004
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Front)
Set type ""HA09A"" nozzle on Head 2 Nozzle 1.
015005
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Rear)
Set type ""FF01""or ""FF02"" nozzle on calibrate position.
015006
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Front)
Set type ""FF01""or ""FF02"" nozzle on calibrate position.
015007
Nozzle Location Check
Already set the different type nozzle.(Rear)
Remove it.
015008 Nozzle Location Check
Already set the different type nozzle.(Front)
Remove it.
015009 Nozzle Location Check
Notfoundttingnozzleforcalibration.(Rear)
Set type ""FF01""or ""FF02"" nozzle on calibrate position.
01500A
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Front)
Set type ""FF01""or ""FF02"" nozzle on calibrate position.
01500B
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Rear)
Set type "VF02" nozzle on calibrate position.
01500C
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Front)
Set type "VF02" nozzle on calibrate position."
01500D
Nozzle Location Check
"Notfoundttingnozzleforcalibration.(Rear)
Set type "HA09A"or "Vf02" nozzle on calibrate position."
01500E
Nozzle Location Check
Notfoundttingnozzleforcalibration.(Front)
Set type "HA09A"or "Vf02" nozzle on calibrate position.
