4OM-1603
2-18
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050706 Shuttle Conveyor
Deceleration Sensor of Input Conveyor in Lane B is detected. Please remove
PCB because there is a possibility that it is inserted.
050707 Shuttle Conveyor
Set Value of Delivery Position of Device System/Input Machine PCB is not in the
Movable Range. Please set the value 467mm and less whose value is the sum
with Y size of PCB.
050708 Shuttle Conveyor
Please set [SMEMA] Mode for Device System/Input Machine Output. And, Please
conrmthatInp/OutpMachineSignalis
setas[Enable].
050709 Shuttle Conveyor
Please set the same value in Lane A / Lane B of Delivery Position of Device
System/Input Machine PCB.
050711 Shuttle Conveyor
Emergency Stop Switch of Shuttle Conveyor in Output side is pressed. Please
cancel it.
050712 Shuttle Conveyor
The safety cover of Shuttle Conveyor in Output side is open. Please close it.
050713 Shuttle Conveyor
Deceleration Sensor of Shuttle Conveyor in Output side is detected. Please
remove PCB there is a possibility that it is inserted.
050714 Shuttle Conveyor
Stop Sensor of Output Conveyor is detected. Please remove PCB there is a
possibility that it is inserted.
050715 Shuttle Conveyor
Stop Sensor of Output Conveyor in Lane A is detected. Please remove PCB there
is a possibility that it is inserted.
050716 Shuttle Conveyor
Stop Sensor of Output Conveyor in Lane B is detected. Please remove PCB there
is a possibility that it is inserted.
050717 Shuttle Conveyor
Set Value of Delivery Position of Device System/Output Machine PCB is not in the
Movable Range. Please set the value 467mm and less whose value is the sum
with Y size of PCB.
050718 Shuttle Conveyor
Please set [SMEMA] Mode for Device System/Output Machine Output. And,
Please
conrmthatInp/OutpMachineSignal
issetas[Enable].
060101 Feeder communication Error
Can not have communication with Feeder. Is Feeder selected Feeder No.
inserted?
060201 Feeder type Error
Library and Feeder are not the same.
060301 Feeder preparation Error
Make Feeder base dropped once. Then, rise it again.
060401 Feeder No. Error
The Feeder is not pickup. Please select another one.
4OM-1603
2-19
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
060501 Nozzle Check
Nozzle is placed. Store it, and then execute.
060601 Cart Check
There is a possibility of Rear/Front of Cart missing. Please set cart normally.
060602 Cart Check
Cart (rear) is not upper position. Please put it up.
060603 Cart Check
Cart (Front) is not upper position. Please put it up.
060604 Cart Check
Cannot operate it because Cart(Rear) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060605 Cart Check
Cannot operate it because Cart(Front) is not at upper position or its connector is
off. ( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
060701 Error in Carrier supplying Cmpnt
Itisimpossibletopick-upthis
cmpntfromspeciedFeeder.Pleasechangethe
Placement mode as [By Hand].
060801 Cutter
Please close and lock the safety cover, and then operate it(Rear).
060802 Cutter
Please close and lock the safety cover, and then operate it(Front).
0d0b01 Cart Check
-----
0d0c01 Pickup miss comp, Disengaged Latch Check
Please open the safety door. Are there no dropped pickup miss comp , no
disengaged Latch? Check them. If the comp was dropped, there is a possibility of
interference with Head.
0d0d01 ConrmbendingNoz
Openthesafetydoor
,andthenconrmwhetherNozplacedinheadisbent.
0d0e01 Zeroing of Cutter is not completed
Execute All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve(Head in
the Rear side). Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve(Head in
the Front side). Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching
Tray's Pallet is not pulled out(Rear). Please pull it out.
0d0f04 Height Teaching
Tray's Pallet is not pulled out(Front). Please pull it out.
0d0f05 Height Teaching
Cannot teach Stocker Master height of the third and forth line for Stocker 2 of One
side Machine,
4OM-1603
2-20
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
0d0f06 Height Teaching
There is no place for Glass Jig in the Head, so that could not teach the height of
Glass Jig.
0d1001 Stop Command
Interlock is detected. Please retry to execute after removing the factor.
0d1101 Flux dispensing unit squeegee error detect
Pleaseputdownsqueegeenotto
separatefromuxdispensingunit.
0d1201 Flux dispensing unit motor warning detect
Pleasetakeout/inuxdispensingand
thenrestarttorun.
0d1301 Uninstalled Flux dispensing unit
Pleasesetuxdispensingunitto
useinpatternprogramdata.
