4b3004 Cutter Error

Cutter-axis Time-out(Zeroing)

-----

4b3005 Cutter Error

Zeroing of Cutter-axis is not completed.

-----

4b3006 Cutter Error

There is a problem in Cutter-axis. (Positioning Operation)

-----

4b3007 Cutter Error

Cutter-axis Time-out(Positioning Operation)

-----

4b3008 Cutter Error

Alarm of Cutter-axis was detected.

-----

4b3009 Cutter Error

Recede operation was executed because alarm was detected during positioning

operation of Cutter-axis.

Please

conrmwhetherthereisan

errorincutterunit(Beingjammedincutter

layer)

4b300a Cutter Error

Can not communicate with SV-NET P.C.B.

PleaseconrmAE-LINKwiringandPower

wiring.

4b300b Cutter Error

Can not communicate with Driver

PleaseconrmPowerwiringandAE-LINK

wiringofdriverinCutterunit.

4b300c Cutter Error

Time-out of waiting for initializing completely

PleaseconrmAE-LINKwiringandPower

wiring.

4b300d Cutter Error

Test mode of cutter is valid.

Please clear the check of [Cutter Movement disable] in the screen of test mode.

4b300e Cutter Error

The set of operation mode of Cutter is "Disable".

Please set operating mode of Cutter "Enable".

4b300f Cutter Error

Cutter can not move because Feeder Base is in downward position.

Please press READY switch of Feeder Base and move Feeder base to input

position.

4b3010 Cutter Error

Cutter can not move because Feeder Base in not positioned correctly.

Please connect connector of Feeder base.

4b3011 Cutter Error

Failed in reading the number of connection axes.

Please

conrmAE-LINKwiringandPower

wiring.

1012-005

4OM-1603

3-108

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

4b3012 Cutter Error

Communication status Error

PleaseconrmAE-LINKwiringandPower

wiring.

4b3013 Cutter Error

Communication status Error(Stand by)

PleaseconrmAE-LINKwiringandPower

wiring.

4b3014 Cutter Error

Communication Status Error(Alarm)

Pleaseconrmthewiringofdriver

inFeederBaseunit

4b3015 Cutter Error

Communication Status Error(OT)

PleaseconrmthewiringofOrigin

Sensor.

4b3016 Cutter Error

Communication Status Error(Connection O)

PleaseconrmAE-LINKwiringandPower

wiring.

4b3017 Cutter Error

Communication Status Error(Driver Alarm)

Pleaseconrmthewiringofdriver

inFeederBaseunit

4b3018 Cutter Error

Communication Status Error(SV-NET stopping)

PleaseconrmAE-LINKwiringandPower

wiring.

4b3019 Cutter Error

Communication Status Error(Out of Connection number)

PleaseconrmAE-LINKwiringandPower

wiring.

4b301a Cutter Error

Communication Status Error(SV-NET Error)

PleaseconrmAE-LINKwiringandPower

wiring.

4b301b Cutter Error

Cutter-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

4b301c Cutter Error

Failed to start-up Communication of SV-NET

PleaseconrmAE-LINKwiringandPower

wiring.

4b301d Cutter Error

Failed to reset Alarm of Cutter-axis

----

4b301e Cutter Error

It returned to its Origin because Alarm of Cutter-axis was detected during

Positioning

Please check Feeder whose Number is close one indicated.

4b301f Cutter Error

Cannotturnontheservomotor

ofcutterunitwithinaspeciedtime.

----

4b3101 Cutter(Servo Error)

Error of Power Driver, Over-current

Check out motor wiring or exchange both motor and driver.

1012-005

4OM-1603

3-109

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

4b3102 Cutter(Servo Error)

Overload Alarm

Check out motor wiring or exchange both motor and driver.

Either,Conrmthattheblocking

existswithcutterpieces.

4b3103 Cutter(Servo Error)

Speed Alarm

Need to adjust motor gain again.

4b3104 Cutter(Servo Error)

Multi-rotation Error

Check motor wiring or exchange motor.

4b3105 Cutter(Servo Error)

The value of Deviation Counter was over the set value

Check the wiring of Origin sensor. Either, Exchange driver.

4b3106 Cutter(Servo Error)

Power Drive detected temperature error.

Ambient Temperature is too high. Exchange driver.

4b3107 Cutter(Servo Error)

Sensor Error

Conrm

thewiringofMotorEncoder

.Either,exchangemotor

4b3108 Cutter(Servo Error)

High Drive voltage

Insufcientpowercapacity.Exchangedriver.

4b3109

Cutter(Servo Error)

Low drive voltage

PleaseconrmtheoperatingPowerwiring

whichisinsertedtodriver.

4b310a Cutter(Servo Error)

Reading Error on permanent memory

Exchange Driver

4b310b Cutter(Servo Error)

Reading Error on permanent memory

Exchange Driver

4b310c Cutter(Servo Error)

CPU Error

Exchange Driver

4b310d Cutter(Servo Error)

Parameter Error

Please

conrmthechangedParameter

4b310e Cutter(Servo Error)

Alarm code readout failed

-----

4b310f Cutter(Servo Error)

Low driving voltage(Rear)(Feeder Base [ON])

-----

4b31

10 Cutter(Servo Error)

Low driving voltage(Front)(Feeder Base [ON])

-----
