4OM-1603 2-28 3. Machine Information : Chap.2 Machine Information Code Display Area A (The outline of the Machine Information) Display Area B (The details of the Machine Information) 80a101 Reading the Linear measure sen…
4OM-1603
2-27
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
809e02 Automatic Teaching
PleaseskipitbecauseAutomaticmodicationT
eachingisimpossibleinNozzle
position of Rear Head.
-----
809f01 Automatic Teaching
There is no magazine. Magazine 1 (Lower).
-----
809f02 Automatic Teaching
Rack shutter of operator side is open. Magazine 1 (Lower)
-----
809f03 Automatic Teaching
Rack shutter of traverse side is open. Magazine 1 (Lower)
-----
809f04 Automatic Teaching
The Magazine is not set correctly. Magazine 1 (Lower)
Check lock lever of magazine.
-----
809f05 Automatic Teaching
There is no magazine. Magazine 2 (Upper).
-----
809f06 Automatic Teaching
Rack shutter of operator side is open. Magazine 2 (Upper)
-----
809f07 Automatic Teaching
Rack shutter of traverse side is open. Magazine 2 (Upper)
-----
809f08 Automatic Teaching
The Magazine is not set correctly. Magazine 2 (Upper)
Check lock lever of magazine.
-----
809f09 Automatic Teaching
Motor Error of Magazine(Lower) is detected.
-----
809f0a Automatic Teaching
Motor Error of Magazine(Upper) is detected.
-----
80a001 Recognition Error
Failed in the recognition of the part. Please retry pickup of the part.
-----
80a002 Recognition Error
Nozzle position teaching failure.
Check nozzle condition.
-----
1012-005
4OM-1603
2-28
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80a101 Reading the Linear measure sensor Version
The operation for turning on is invalid.
Please do operation again after turning on completely.
-----
80b001 Automatic Teaching Error
Failed in the recognition. Carr it out again on the next time.
-----
80c001 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Rear) Magazine1(Lower).
PleaseconrmthewiringofMachine
-----
80c002
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Rear) Magazine1(Upper).
PleaseconrmthewiringofMachine
-----
80c003
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Front) Magazine2(Lower).
PleaseconrmthewiringofMachine
-----
80c004
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Front) Magazine2(Upper).
PleaseconrmthewiringofMachine
-----
80c101
Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Rear) Magazine1(Lower)
-----
80c102 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Rear) Magazine2(Upper)
-----
80c103 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Front) Magazine1(Lower)
-----
80c104 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Front) Magazine2(Upper)
-----
80c201 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Rear) Magazine1(Lower) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c202 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Rear) Magazine2(Upper) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
1012-005
4OM-1603
2-29
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c203 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Front) Magazine1(Lower) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c204 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Front) Magazine2(Upper) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c301 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Rear)
Magazine1(Lower).
-----
80c302 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Rear)
Magazine2(Upper).
-----
80c303 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Front)
Magazine1(Lower).
-----
80c304 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear lock because Cmpnt shortage is not found on Tray(Front)
Magazine2(Upper).
-----
80c401 Nozzle Exchange
There are neither a free space nor a nozzle for nozzle exchange.
-----
80c402 Nozzle Exchange
There is no free space for Nozzle in Stocker.
Please take off unnecessary Nozzle from Stocker, and then update the nozzle
data.
-----
80c403 Nozzle Exchange
ODD Noz of Head is stored for storing high-speed Noz.
-----
80c404 Nozzle Exchange
Noz is stored due to error in teaching Noz Position.
-----
80c501 Overall Setup(Exchange support pin)
Pattern Program data set the support pin as [No exchange], so that skipped it.
-----
80c502 Overall Setup(Exchange support pin)
Noz is not for Support Pin Exchange, so that it is stored.
-----
1012-005
