4OM-1603 3-68 3. Error IDs and Remedial Procedures : Chap.3 Error ID Error Name, Description, Cause, and Remedy 448506 Multi-T ray(Front) Communication Status Error(Connection O) Pleaseconrm AE-LINKwiringandPower …

4OM-1603

3-67

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

44181c Tray Feeder in advance check error

Magazine(Upper) is not done Positioning yet.

PleaseconrmtheMagazinepositionand

Magazinelocklever.

441820 Tray Feeder in advance check error

Zeroing incomplete

-----

444001 Tray Feeder Sequence Error (Front)

Tray feeder sequence timeout

-----

448302 Elevator Unit Exchange (Attach) (Front)

Elevator Unit is not detected.

Please set up Tray Unit in Exchange location.

448303 Elevator Unit Exchange (Attach) (Front)

Connector of Feeder base is not positioned correctly.

Please Operate it after connecting connector of Feeder Base.

448304 Elevator Unit Exchange (Attach) (Front)

Connector of Tray is not positioned correctly.

Operate it after connecting connector of Tray.

448305 Elevator Unit Exchange (Attach) (Front)

Time-out of Clamp operating of Elevator Unit.

-----

448306 Elevator Unit Exchange (Attach) (Front)

Feeder Base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

448402 Elevator Unit Exchange (Detach) (Front)

Time-out of Unclamp operating of Elevator Unit.

-----

448403 Elevator Unit Exchange (Detach) (Front)

Feeder Base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

448501 Multi-Tray(Front)

Time-out of waiting for initialization

Please

conrmAE-LINKwiringandPower

wiring.

448502 Multi-Tray(Front)

Can not communicate Driver.

PleaseconrmAE-LINKwiringandPower

wiring.

448503 Multi-Tray(Front)

Communication Status Error(Stand by)

PleaseconrmAE-LINKwiringandPower

wiring.

448504 Multi-Tray(Front)

Communication Status Error(Alarm)

PleaseconrmAE-LINKwiringandPower

wiring.

448505 Multi-Tray(Front)

Communication Status Error(OT)

PleaseconrmAE-LINKwiringandPower

wiring.

1012-005

4OM-1603

3-68

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448506 Multi-Tray(Front)

Communication Status Error(Connection O)

PleaseconrmAE-LINKwiringandPower

wiring.

448507 Multi-Tray(Front)

Communication Status Error(Driver Alarm)

PleaseconrmAE-LINKwiringandPower

wiring.

448508 Multi-Tray(Front)

Communication Status Error(SV-net stopping)

PleaseconrmAE-LINKwiringandPower

wiring.

448509 Multi-Tray(Front)

Communication Status Error(Out of Connection number)

PleaseconrmAE-LINKwiringandPower

wiring.

44850A Multi-Tray(Front)

Communication Status Error(SV-VET Error)

PleaseconrmAE-LINKwiringandPower

wiring.

44850B Multi-Tray(Front)

Failed to read the number of Axes

PleaseconrmAE-LINKwiringandPower

wiring.

44850C Multi-Tray(Front)

Driver-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

44850D Multi-Tray(Front)

Elevator1-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

44850E Multi-Tray(Front)

Elevator2-aixs in not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

448510 Multi-Tray(Front)

Motor Breaker Trip Error

-----

448511 Multi-Tray(Front)

Elevator Unit is not connected.

Please connect Elevator unit in Unit exchange menu.

448512 Multi-Tray(Front)

All connectors of Elevator Unit are not connected.

Pleaseconrmtheconnectiontoall

connectorofElevatorUnit

448513 Multi-Tray(Front)

Failed to start-up Communication of SV-NET.

PleaseconrmAE-LINKwiringandPower

wiring.

448514 Multi-Tray(Front)

Failed to turn on Multi-tray.(Time-out)

-----

448515 Multi-Tray(Front)

(AtnishingAutoRun)Multi-trayoperation(Front)

isnotcompletedwithina

speciedtime.

Please Push Emergency Stop button.

1012-005

4OM-1603

3-69

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

448601 Multi-Tray (Servo Error) (Front)

Error of Power Driver, Over-current

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

448602 Multi-Tray (Servo Error) (Front)

Overload Alarm

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

448603 Multi-Tray (Servo Error) (Front)

Speed Alarm

You need to re-adjust Motor Gain.

448604 Multi-Tray (Servo Error) (Front)

Multi-rotation Error

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

448605 Multi-Tray (Servo Error) (Front)

The value of Deviation Counter was over the set value

PleaseconrmthewiringofOrigin

Sensor,orexchangeDriver.

448606 Multi-Tray (Servo Error) (Front)

Power Drive detected temperature error.

Ambient Temperature is too high. Or, exchange driver.

448607 Multi-Tray (Servo Error) (Front)

Sensor Error

PleaseconrmMotorEncoderwiring.Or

,exchangemotor

448608 Multi-Tray (Servo Error) (Front)

High Drive voltage

Insufcientpowercapacity.Pleaseexchange

driver.

448609 Multi-Tray (Servo Error) (Front)

Low drive voltage

PleaseconrmtheoperatingPowerwiring

whichisinserteddriver.

44860A Multi-Tray (Servo Error) (Front)

Reading Error on permanent memory

Please exchange driver.

44860B Multi-Tray (Servo Error) (Front)

Writing Error on permanent memory

Please exchange driver.

44860C Multi-Tray (Servo Error) (Front)

CPU Error

Please exchange driver.

44860D Multi-Tray (Servo Error) (Front)

Parameter Error

Please

conrmthechangedparameter.

44860E Multi-T

ray (Servo Error) (Front)

Alarm code readout failed

-----

448701 Elevator Recede position operating error (Front)

Elevator pre-check error

-----

1012-005
