4OM-1603 2-30 3. Machine Information : Chap.2 Machine Information Code Display Area A (The outline of the Machine Information) Display Area B (The details of the Machine Information) 80c503 Overall Setup(Exchange support…
4OM-1603
2-29
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c203 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Front) Magazine1(Lower) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c204 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Front) Magazine2(Upper) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c301 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Rear)
Magazine1(Lower).
-----
80c302 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Rear)
Magazine2(Upper).
-----
80c303 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray(Front)
Magazine1(Lower).
-----
80c304 Multi-layered Tray Safety Cover Lock cleared(Auto Run)
Cannot clear lock because Cmpnt shortage is not found on Tray(Front)
Magazine2(Upper).
-----
80c401 Nozzle Exchange
There are neither a free space nor a nozzle for nozzle exchange.
-----
80c402 Nozzle Exchange
There is no free space for Nozzle in Stocker.
Please take off unnecessary Nozzle from Stocker, and then update the nozzle
data.
-----
80c403 Nozzle Exchange
ODD Noz of Head is stored for storing high-speed Noz.
-----
80c404 Nozzle Exchange
Noz is stored due to error in teaching Noz Position.
-----
80c501 Overall Setup(Exchange support pin)
Pattern Program data set the support pin as [No exchange], so that skipped it.
-----
80c502 Overall Setup(Exchange support pin)
Noz is not for Support Pin Exchange, so that it is stored.
-----
1012-005
4OM-1603
2-30
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80c503 Overall Setup(Exchange support pin)
Noz for Support Pin Exchange on Head is not found.
-----
80c504 Overall Setup(Exchange support pin)
Conveyor Width is stopped at the position for exchanging support pins because
the Support pins of Lane A are stored. Please take out Support pins from
machine, or install Conveyor Width after setting them at production position.
-----
80c601 Overall Setup(Conveyor width setup)
Pattern Program data set the conveyor width as [No Setup]. So that skipped it.
-----
80c701 Nozzle Level Offset Teaching
All E/NR from linear measure sensor is detected.
Pleaseconrmitbecausethereis
apossibilitythatODDNozisplaced.
-----
80c702 Nozzle Level Offset Teaching
Could not do Teaching because Noz for measurement on Head(Rear) is not set.
-----
80c703 Nozzle Level Offset Teaching
Could not do Teaching because Noz for measurement on Head(Front) is not set.
-----
80c704 Nozzle Level Offset Teaching
The Length of measured Noz is out of Allowable Range.
PleaseconrmtheNozofHead.
-----
80c801
Cutter Auto Reset
Cutter Auto Reset of Device(Rear) is executed.(The 1st)
-----
80c802 Cutter Auto Reset
Cutter Auto Reset of Device(Front) is executed.(The 1st)
-----
80c803 Cutter Auto Reset
Cutter Auto Reset of Device(Rear) is executed.(The 2nd)
-----
80c804 Cutter Auto Reset
Cutter Auto Reset of Device(Front) is executed.(The 2nd)
-----
80c805 Cutter Auto Reset
Cutter Auto Reset of Device(Rear) is executed.(The 3rd)
-----
80c806 Cutter Auto Reset
Cutter Auto Reset of Device(Front) is executed.(The 3rd)
-----
80e001 Noz Selection axis position offset teaching
The 1st Re-trial for Noz Selection axis position offset teaching started.
-----
1012-005
4OM-1603
2-31
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80e002 Noz Selection axis position offset teaching
The 2nd Re-trial for Noz Selection axis position offset teaching started.
-----
80f001 Auto Opn.Mode
Start Auto Opn.Mode.
-----
80f002 Auto Opn.Mode
Stop Auto Opn.Mode.
-----
80f101 ACV Registration
Comp.Reld. execution.
-----
80f102 ACV Registration
Splicing execution.
-----
80f201 Simplied
Coverlocked
OperatedbySimpliedCover
locked.PleaseconrmthepositionofbothHeads
and Nozzle. There is a possibility of interference when they are close to Transfer
machine. Continue to operation.
-----
80f202 SimpliedCoverlocked
Connector(Rear) of Feeder Base is taken off.
Do not take it off when Feeder Base is rising up. Please go on if it's on operating.
-----
80f203 SimpliedCoverlocked
Connector(Front) of Feeder Base is taken of
f.
Do not take it off when Feeder Base is rising up. Please go on if it's on operating.
-----
80f204 SimpliedCoverlocked
Manual Movement and Load.
This operation will be done while [START] button is
pushed.
Please push the button continuously before PCB moves to the proposal position.
-----
80f301 Barcode Detection
The bar code data is not read. Bar code ID is generated automatically.
-----
80f302 Barcode Detection
Illegal bar code ID. Bar code ID is generated automatically
.
-----
80f401 FF func. for Print Pos Correction
Standard PCB Mounting will be executed without Print Pos. Correction because
the standard of Device's Coordinates for PP data in Printer differs from it in
Mounter.
-----
