4OM-1603
3-16
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
403801 Tray Safety Door(Center)
Safety door (center) of tray feeder unit opened.(Rear)[S0503]
Close the safety door(Upper) and operate it.
403901 Pallet Chuck Claw(Rear)
Chucking lever of pallet opened while elevator is moving.(Rear)
[B15407, B15408]
Check out detecting Sensor (B15407, B15408) of closing Chucking lever of pallet.
403A01 Palletyingaway(Rear)
Thepalletyingaway
whileelevatorismoving.(Rear)[B15406]
Check out detecting sensor (B15406) of breaking out Pallet and position of Pallet.
403B01 Detecting pickup miss cmpnt on Tray Pallet (Rear)
Detect pickup miss components on the pallet. (Rear)[B15417]
Please open the main cover and remove pickup miss components on the pallet.
403C01 Detecting pickup miss cmpnt on Tray Pallet (Rear)
Detect pickup miss components on the pallet. (Rear)[B15418]
Please open the main cover and remove the pickup miss components on tray
pallet.
403D01 Detecting pickup miss cmpnt on Tray Pallet (Rear)
Detect pickup miss components on the pallet. (Rear)[B15419]
Please open the main cover and remove the pickup miss components on tray
pallet.
403E01 Detecting Lower Magazine rack shutter (Rear)
Open the rack shutter while lower elevator is moving.(Rear)
[B15521][B15523][B15525]
Check out the sensor (B15521, B15523, B15525) of closing magazine rack
shutter.
403F01 Detecting Upper Magazine rack shutter (Front)
Open the rack shutter while upper elevator is moving.(Rear)
[B15527][B15529][B15531]
Check out the sensor (B15527, B15529, B15531) of closing magazine rack
shutter.
404001 Lower magazine positioning error(Rear)
Lower magazine positioning error(Rear) [B15526]
Check Magazine Clamp.
404101 Upper magazine positioning error(Rear)
Upper magazine positioning error.(Rear) [B15532]
Check Magazine Clamp.
404201 Shut-off Motor Breaker for Tray (Rear)
Tripped circuit breaker of motor (Rear).
Please turn on again after turning off and cancelling Trip mode.
404301 Shut-off safety relay of Elevator(Lower) (Rear)
Cut off safety relay of lower elevator (Rear).
Check the main circuit and safety door.
404401 Shut-off safety relay of Elevator(Upper) (Rear)
Cut off safety relay of upper elevator (Rear).
Check the main circuit and safety door.
4OM-1603
3-17
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
404501 Elevator Unit Clamp released (Rear)
Released clamp of elevator unit (Rear)[B15426, B15428]
Check out Elevator unit clamp sensor(B15426, B15428).
404601 Detecting pickup miss cmpnt of Tray Feeder Cart (Rear)
Detecting pickup miss cmpnt(Rear) [B15412]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatch
andremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
404701 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Rear)
Feeder Disengaged Latch is detected.(Rear)[B15412]
1. Open the cover.
2. Conrmsuppressor,DisengagedLatch
andremovethePickupmisscmpnt.
3. Close the cover and then Lock it.
404801 Detecting Emergency Stop(Front)
Emergency stop(Front) is detected
Please turn on the main body and operate it.
404901 Tray Safety Door(Lower)(Front)
Safety door(Lower) of tray feeder unit opened.(Front)[S0501]
Please close the safety door(lower) and operate it.
404A01 Tray Safety Door(Upper)(Front)
Safety door(Upper) of tray feeder unit opened.(Front)[S0502]
Please close the safety door(upper) and operate it.
404B01 Tray Safety Door(Center)(Front)
Safety door(Center) of tray feeder unit opened.(Front)[S0503]
Please close the safety door(center) and operate it.
404C01 Pallet Chuck Claw(Front)
Pallet Chuck Claw opened while elevator is moving.(Front)[B15407, B15408]
Check out detection Sensor of closing Chucking lever of pallet (B15407, B15408).
404D01 Pallet
yingaway(Front)
Palletyingaway
duringelevatormoving.(Front)[B15406]
Check out detecttion sensor of breaking out Pallet (B15406) and position of Pallet.
404E01 Detecting pickup miss cmpnt on Tray Pallet (Front)
Pickup misscmpnt on the Pallet is detected.(Front) [B15417]
Open the main cover and remove pickup miss components on the Tray Pallet.
404F01 Detecting pickup miss cmpnt on Tray Pallet (Front)
Pickup miss cmpnt on the Pallet is detected.(Front) [B15418]
Open the main cover and remove pickup miss components on the Tray Pallet.
405001 Detecting pickup miss cmpnt on Tray Pallet (Front)
Pickup miss components on the Pallet is detected.(Front) [B15419]
Open the main cover and remove pickup miss components on the Tray Pallet.
405101 Detecting lower Magazine rack shutter (Front)
the rack shutter opening is detected during lower elevator moving.(Front)
[B15521, B15523,B15525]
Check out the sensor of closing magazine rack shutter (B15521, B15523,
B15525).
1012-005
4OM-1603
3-18
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
405201 Detecting upper Magazine rack shutter (Front)
the rack shutter opening is detected during upper elevator moving. (Front)
[B15527, B15529,B15531]
Check out the sensor of closing magazine rack shutter (B15527, B15529,
B15531).
405301 Lower magazine positioning error (Front)
Lower magazine positioning error.(Front)[B15526]
ConrmMagazineClamp.
405401 Upper magazine positioning error (Front)
Upper magazine positioning error.(Front)[B15532]
ConrmMagazineClamp.
405501
Shut-off Motor Breaker for Tray (Rear)
Tripped circuit breaker of motor (Front)
Please turn on again after turning off and cancelling
Trip mode.
405601 Shut-off safety relay of Elevator(Lower) (Front)
Cut off safety relay of lower elevator (Front).
Conrmthemaincircuitandsafety
door.
405701 Shut-off safety relay of Elevator (Upper) (Front)
Cut off safety relay of upper elevator (Front).
Conrmthemaincircuitandsafety
door.
405801 Released Elevator unit clamp (Front)
Released elevator unit clamp (Front) [B15426, B15428]
ConrmtheElevatorUnitClampSensor(B15426,
B15428).
405901 Detecting pickup miss cmpnt of Tray Feeder Cart (Front)
Pickup miss components was detected (Front). [B15412]
1.Openthecover.\r\n2.Conrmsuppressor,
DisengagedLatchandremovethe
Pickup miss cmpnt.\r\n3.Close the cover and then Lock it.
405A01 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Front)
Feeder Disengaged Latch is detected [B15412]
1.Openthecover.\r\n2.Conrmsuppressor,
DisengagedLatchandremovethe
Pickup miss cmpnt.\r\n3.Close the cover and then Lock it.
407001 Detecting Head (Rear) nozzle descending
Invalid detection of head (Rear) nozzle descending
Please perform a zeroing.
407101 Detecting Head (Front) nozzle descending
Invalid detection of head (Front) nozzle descending
Please perform a zeroing.
407201 Pass Line detect (Rear)
Invalid detection of Pass line (Rear)
Please perform a zeroing.
407301 Pass Line detect(Front)
Invalid detection of Pass line (Front)
Please perform a zeroing.
T4C3
1012-005
