1.3 Items for Periodic Maintenance
The items (inspection, cleaning, lubrication, etc.) that require periodic
maintenance are classied and described based on each individual devices.
Reference
Refer to "2. Maintenance Check List" for the maintenance based on frequency
of use.
Notice
The * -marks represent that the items require maintenance only for the
rsttime.
Followthe○-markedmaintenancecycleforthesubsequentuse.
Device Name
Inspection Cleaning,
and Lubricating Spots
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
3.2.1 Air Source
Main Air Pressure
Inspection
○
Air Blowing Pressure
Inspection
○
Z Clamp Pressure
Inspection
○
Drain
Cleaning
○
Filter
Cleaning
○
3.2.2 Vacuum System
Vacuum Pressure
Inspection
○
Filter
Cleaning
○
3.2.3 Component
Recognition Camera
Section
Component Recognition
Camera
Cleaning
○
Component Storage Box
Cleaning
○
Hanenaito
Cleaning
○
Fiducial Mark
Cleaning
○
QFP Glass Plate Jig
Cleaning
○
Teaching Plate
Cleaning
○
3.2.4 Feeder Base
Driving Section
Worm Gear
Lubrication
○
3.2.5 Feeder Cart Section
Groove on Feeder Base
Cleaning
○
Upper Surface of Feeder
Base
Cleaning
○
Real Box
Cleaning
○
Scrap Box
Cleaning
○
Upper Surface of
Suppressor
Cleaning
○
T4A6
1003-003
4OM-1603
1-9
1. Outline of Maintenance : Chap.1
Device Name
Inspection Cleaning,
and Lubricating Spots
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
3.2.6 Feeder Cart Section
(Cutter Section)
Cutter Box
Cleaning
○
Linear Guide
Lubrication
○
Flat Ring
Change
○
Fluorine Sheet
Change
○
Urethane Clamp
Change
○
Needle Bearing
Lubrication
○
3.2.7 Head Section
(High Speed Head)
Nozzle U/D Ball Screw
(NL Axis)
Cleaning,
Lubrication
○
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
○
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
○
Nozzle Shaft
Inspection,
Cleaning
○
Diffusion Plate
Cleaning
○
Linear Measure Sensor
(Light Emitter and
Receiver)
Cleaning
○
Nozzle Change Cam Face
(Lower Side)
Cleaning,
Lubrication
○
Center Spline
Lubrication
○
Cam Follower
Cleaning,
Lubrication
○
Vacuum Filter
Change
○
Vacuum Nozzle
Cleaning
○
Vacuum Nozzle
Inspection
○
Nozzle Filter
Change
○
3.2.7 Head Section
(Multi-Functional
Head)
Ball Screw
(3 locations)
Lubrication
○
Linear Guide
(3 locations)
Lubrication
○
Pan
(3 locations)
Cleaning
○
Vacuum Filter
Change
○
Vacuum Nozzle
Change
○
Vacuum Nozzle
Inspection
○
T4A7
1012-005
4OM-1603
1-10
1. Outline of Maintenance : Chap.1
Device Name
Inspection Cleaning,
and Lubricating Spots
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
3.2.8 X/Y Beam Section
X-Axis Linear Guide
Inspection
○
X-Axis Linear Guide
Cleaning,
Lubrication
*
○
Y-Axis Linear Guide
Inspection
○
Y-Axis Linear Guide
Cleaning,
Lubrication
*
○
X-Axis Cable Side Face
Cleaning,
Lubrication
○
X-Axis Cable Fixing
Places
Inspection
○
X-Axis Linear Scale
Cleaning
○
Y-Axis Cable Side Face
Cleaning,
Lubrication
○
Y-Axis Cable Fixing
Places
Inspection
○
Y-Axis Linear Scale
Cleaning
○
3.2.9 PCB Positioning
Section
Upper Surface of Backup
Table
Cleaning
○
Ball Screw
Cleaning,
Lubrication
*
○
Ball Screw Splines
Cleaning,
Lubrication
○
3.2.10 Conveyor Section
Linear Guide
Cleaning,
Lubrication
*
○
Support Pin Detection
Sensors
Cleaning,
Lubrication
○
PCB Detection Sensor
Cleaning
○
PCB Detection Sensor
Fiber
Cleaning
○
PCB Detection Sensor
Mirror
Cleaning
○
3.2.11 Nozzle Stocker
Section
Nozzle Storage Section
Cleaning
○
Nozzle Stocker Sliding
Area
Cleaning,
Lubrication
○
Shutter Flange Pin Sliding
Section
Cleaning,
Lubrication
○
3.2.12 Control Box
Section
Filter
Cleaning
○
3.2.13 Fans
Ventilating Fan
Cleaning
○
Air-Intake Fan
Cleaning
○
