4OM-1603
3-21
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
420101 Backup L Axis Error.
The movement of Backup (L) Axis was not completed within predetermined time.
Backup axis is unable to do upward movement and downward movement.
The problem is for Motor, Driver, Sensor Error or wiring Error.
Please check the motor, sensor on Machine check screen.
420102 Backup L Axis Error.
Driver Alarm on Backup (L) Axis
Check out reset Method of detailed Sub-system error counts of Alarm.
420103 Backup L Axis Error.
Error in calculating data of Backup (L) Axis
Please check the following data
1. Machine Offset/Backup Pin(Up & Down)
2. Pattern program/P.C.B. information/P.C.B. size/thickness
3. Control/Common/PRE-PLACED CMPNT THKNS/Bottom of P.C.B.
420104 Backup L
Axis Error.
Time-over of zeroing of Backup (L) Axis
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
420105 Backup L Axis Error.
Time Over of the upward movement of stopper (L)
1. Check out the P.C.B. between stopper and conveyor
2. Error in Up/Down detection sensor. Check out the sensor input
3. Disconnection, Error of Movement output. Please check Stopper by manual
movement if sensor input is proper.
4. Please set speed again by adjusting speed control when stopper is slow.
420106
Backup L Axis Error.
Time-over of downward Stopper(L)
1. Up/Down Detect Sensor is out of order. Please check Sensor input
2.
Disconnection/Error of output. Please check Stopper by manual movement if
sensor input is proper.
3. Please set speed again by adjusting speed control when stopper is slow.
420107 Backup L
Axis Error.
Communication Error of the command of P.C.B. positioning (Backup)
Error in Motor Driver, Communications trouble(AE-LINK), Error in Communication
P.C.B.(API). Check out the wiring of Communication line, power supply line.
420108
Backup L Axis Error.
Backup Pin/Jig under the conveyor belt is detected.
Check out the interference in Belt on Backup Base does not exist.
420110 Backup (L) Error
Not ready for System setup of Backup (L) axis
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
4OM-1603
3-22
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
420111 Backup(L) Error
Error in zeroing in Backup(L) axis
LS, discontinuous zeroing movement, was detected. Check out the dirt, error of
sensor and error in Motor body etc.
420112 Backup(L) Error
Out-of-Control in Backup(L) axis is detected
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production. Please set motor
speed slow if it happens frequently. Also, in a case of structure motor Error.
420113 Backup(L) Error
Error in motor power voltage of Backup(L) axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
420114 Backup(L) Error
STP input of Backup(L) Axis is detected
STP input is detected. The function to stop motor by Hard signal.
420115 Backup(L) Error
Over-current of Backup(L)
Error in Motor output line. Check out the motor wiring.
420116 Backup(L) Error
Limit Sensor(+) of Backup(L) axis is detected
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
420117 Backup(L) Error
Limit Sensor(-) of Backup(L) axis is detected
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
420118 Backup(L) Error
Disconnecting Motor of Backup(L) axis is detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
420119 Backup(L) Error
Error in the Control Power Voltage of Backup(L) axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42011a Backup(L) Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
42011b Backup(L) Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
42011c Backup(L) Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
42011d Backup(L) Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
4OM-1603
3-23
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
42011e Backup(L) Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
42011f Backup(L) Error
System Error of Backup(L) axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
420120 Backup(L) Error
Communication Error of the Backup(L) axis
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3.ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
420201 Backup(R) Axis Error
The Backup(R) Axis was not completed within predetermined time.
Backup axis is unable to do upward movement and down movement.
The factor is for Motor, Driver, Sensor Error or wiring Error.
Please check the motor, sensor on Machine check screen.
420202 Backup(R) Axis Error
Driver Alarm on Backup(R) Axis
ConrmresetMethodofdetailedSub-system
errorcountsofAlarm.
420203 Backup(R) Axis Error
Error in calculating data of positioning command of Backup(R) Axis
Pleaseconrmthefollowingdata.
1. Machine Offset/Backup Pin(Up/Down)
2.
Pattern Program/P.C.B. Information/P.C.B. size/Thickness
3. Control/Common/PRE-PLACED CMPNT THKNS/Bottom of P.C.B.
420204 Backup(R) Axis Error
Time-over of zeroing of Backup(R) Axis
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
420205 Backup(R) Axis Error
Time-over of the upward movement of stopper(R)
1. PleaseconrmwhetherP.C.B.is
caughtbetweenstopperandconveyor.
2. Error in Up/Down detecting sensor. Please check sensor input.
3. Disconnection/ErrorofOutput.Pleaseconrmthestopperbymanualifsensor
input is correct.
4. Please reset the speed by adjusting speed control when stopper is slow.
420206 Backup(R) Axis Error
Time-over of the downward movement of stopper(R)
1. Errorin
Up/Downdetectingsensor.
Conrmthesensor.
2. Disconnection/ErrorofOutput.Pleaseconrmthestopperbymanualifsensor
input is correct.
3. Please reset the speed by adjusting speed control when stopper is slow.
