4OM-1603
3-42
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
425110 Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted in P-OUT valid mode.
425111 Detection of Input conveyor sensor
There is a possibility of interference between output PCB and input PCB.
PassingPCBoccurredduringsimultaneoustransfer
.Pleaseconrmthatoutputis
running without problems.
425201 Input conveyor timeout
Placement was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the transition with Input Machine.
425202 Input conveyor timeout
Output was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the above conveyor.
425301 Input conveyor Error
Error in Input conveyor
-----
426101 Detection of positioning conveyor sensor
Decrease sensor of input position was detected before starting.
There
isanindeniteP.C.B.
onInputpositiondeceleratingsensor.
Please remove P.C.B..
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
ThereisanindeniteP.C.B.
onInputpositionstopsensor.PleaseremoveP.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after starting.
Thereisan
indeniteP.C.B.
onInputpositiondeceleratingsensor.Pleaseremove
P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426107 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
Thereisan
indeniteP.C.B.
onInputpositionstopsensor.PleaseremoveP.C.B..
4OM-1603
3-43
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
426108 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
Thereisan
indeniteP.C.B.
onOutputpositiondeceleratingsensor.Please
remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
Therei
saninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610c Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610d Detection of positioning conveyor sensor
Decrease sensor of output position was detected after starting.
Therei
saninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610e Detection of positioning conveyor sensor
Decrease sensor of output position was not detected after starting.
-----
42610f Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
Thereisaninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
426110 Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426111 Detection of positioning conveyor sensor
P.C.B. on positioning conveyor was detected
Please remove P.C.B. from positioning conveyor
.
426112 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
ConrmwhetherP.C.B.isnot
dropping.ConrmwhetherSensorisnotbroken.
426113 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
PassingPCBoccurredduringsimultaneoustransfer
.Pleaseconrmthatoutputis
running without problems.
4OM-1603
3-44
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
426201 positioning conveyor timeout
Placement for input position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input conveyor to Input
positionorisdropped.Pleaseconrm
fromInputtopositioningconveyor.
426202 positioning conveyor timeout
Output from input position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input position to Output or is
dropped.Pleaseconrmfrompositioningto
Outputconveyor.
426203 positioning conveyor timeout
Placement for output position was not completed within predetermined time.
P.C.B. inserted is place in Output position. There is a possibility of it fallen. Please
conrmfromInputtoPositioningconveyor
.
426204 positioning conveyor timeout
Output from output position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input position to Output or is
dropped.Pleaseconrmfrompositioningto
Outputconveyor.
426301 positioning conveyor Error
Error in positioning conveyor
-----
427101 Detection of Output conveyor sensor
Decrease sensor was detected before starting.
ThereisanindeniteP.C.B.
onOutputconveyor.Pleaseremoveit.
427102 Detection of Output conveyor sensor
Decrease sensor was not detected before starting the movement
P.C.B. to output is not found
1. Please put P.C.B. on Sensor.
2. Thereisapossibility
ofP.C.B.fallen.Conrmtheconveyorwidth.
427103 Detection of Output conveyor sensor
Stop sensor was detected before starting.
ThereisanindeniteP.C.B..
Pleaseremoveit.
427104 Detection of Output conveyor sensor
Stop sensor was not detected before starting.
CannotndP.C.B.tooutput.
1. Is P
.C.B. detected by sensor?
2. There is a possibility that P.C.B. is falling. Please check the width of conveyor.
427105 Detection of Output conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
ThereisanindeniteP.C.B.
onOutputconveyor.Pleaseremoveit.
427106 Detection of Output conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
427107 Detection of Output conveyor sensor
P.C.B. on stop sensor was detected after movement completion
Thereis
anindeniteP.C.B.
onOutputconveyor.Pleaseremoveit.
