4OM-1603
3-104
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b2304 Feeder (Servo Error)
Alarm Code:A3 - Others
-----
4b2305 Feeder (Servo Error)
Alarm Code:A4 - Main Circuit Power Supply Error (Please check the power supply
voltage.) (G04)
Please check the power supply voltage.
4b2306 Feeder (Servo Error)
Alarm Code:A5 - Fault Speed Error (Tape catching)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponents
anddustarebeingcaughtinthetape
feeding gear.
4b2307 Feeder (Servo Error)
Alarm Code:A6 - Others
-----
4b2308 Feeder (Servo Error)
Alarm Code:A7 - Fault Load Error (Tape twisting, Catching foreign substances)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponents
anddustarebeingcaughtinthetape
feeding gear.
4b2309 Feeder (Servo Error)
Alarm Code:A8 - Encoder Error (Breaking wire, Breakdown of control P.C.B. and
Defective servo motor)
Please replace the feeder.
4b230a Feeder (Servo Error)
Alarm Code:Ab - System Error
Please replace the feeder. (It may be caused by trouble of the control P.C.B..)
4b230b Feeder (Servo Error)
Alarm Code:Ac - Reckless Run Detection Error
Please replace the feeder. (It may be caused by trouble of the control P.C.B..)
4b230c Feeder (Servo Error)
Alarm Code:Ad - Excessive deviation in position
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b2401 Feeder (Movement Error)
Alarm Code:E0 - (1) Damaged cover tape/ (2) Cover tape jammed in the storage/
(3) Splicing section peeling off
(1)
Conrmwhetherornotthe
covertapeissetcorrectly
(2) Please remove the cover tape from the storage section.
(3) Please check the splicing condition if the work performed correctly in the
process.
4OM-1603
3-105
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b2402 Feeder (Movement Error)
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
(1)Conrmwhetherornotthe
covertapeissetcorrectly.
(2)Conrmwhetherornotsomestickymaterialhasadheredtothesuppressor.
(3)Conrmthesplicingconditioniftheworkperformedcorrectlyintheprocess.
4b2403 Feeder (Movement Error)
Alarm Code:E2 - Origin Position Checking Error (Excessively out of the origin
during servo ON)
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b2405 Feeder (Movement Error)
Alarm Code:E4 - Positioning Completion Timeout (Foreign substances in the
sprocket wheel)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
4b2407 Feeder (Movement Error)
Alarm Code:E6 - Lane Change Timeout Error
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b2408 Feeder (Movement Error)
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b2410 Feeder (Movement Error)
A pickup error occurred due to feeder operation problem.
Please check the feeder and the component.
-----
4b2411 Feeder (Movement Error)
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Conrm
whetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponents
anddustarebeingcaughtinthetape
feeding gear.
4b2412 Feeder (Movement Error)
ErrorinconrmingconnectionofFeeder
Please check connection of Feeder
4b2413
Feeder (Movement Error)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b24a3 Feeder (Movement Error)
Feeder error (feeding time-out)
-----
4OM-1603
3-106
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b2501 Splicing Operation failed
Alarm Code:E3 - (1)No supplied history/ (2)Dirty splicing detection sensor (dust
adhesion)
(1) Please operate to resupply components in the machine after splicing
operation.
(2) Please clean the joint detection sensor.
4b2601 Unit P.C.B. B.B.R. Information
There is no information in the relevant P.C.B. (on the Transfer Conveyor).
Delete the BBR information after removing the P.C.B..
4b2602 Unit P.C.B. B.B.R. Information
There is no information in the relevant P
.C.B. (on the Transfer XY-Table).
Delete the BBR information after removing the P.C.B..
4b2603 Unit P.C.B. B.B.R. Information
A problem was found in the unit PCB BBR information.
Delete the BBR information after removing the P.C.B..
4b2701 Start Process(Feeder Connection Error)
Aspecialfeederisappointed.Please
conrmthemodelofasetfeeder.
-----
4b2711 Start Process(Feeder Connection Error)
ACVCheckError.ComponentID
onthefeederisnotsameasonespeciedby
current program.
-----
4b2713 Start Process(Feeder Connection Error)
There is a splicing failure feeder.
-----
4b2722 Start Process(Feeder Connection Error)
Feeder is not ready
-----
4b02803 PCB-ID communication Error.
A problem was found in the unit PCB ID information.
Delete the P.C.B.-ID information after removing the P.C.B.
4b2c01 Error in connection between CPU
Failed in communications with the Control CPU.
-----
4b2c02 Error in connection between CPU
Failed in communications with the Recog. CPU.
-----
4b3001 Cutter Error
Program Error(There is a operation mode which is not set)
-----
4b3002 Cutter Error
There is a problem in Cutter-axis. (Zeroing operation)
-----
4b3003 Cutter Error
There is a time-out in Cutter-axis.(Zeroing operation start)
-----
1012-005
