4OM-1603
3-64
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
44160a Tray Feeder Zeroing Error (Front)
Pallet chuck close error
-----
44160b Tray Feeder Zeroing Error (Front)
Rack shutter CLOSE error
-----
44160c Tray Feeder Zeroing Error (Front)
Elevator zeroing error
-----
44160d Tray Feeder Zeroing Error (Front)
EV1 step logs and step movement error
-----
44160e Tray Feeder Zeroing Error (Front)
Ev2 step logs and step movement error
-----
44160f Tray Feeder Zeroing Error (Front)
Traverse zeroing error
-----
441610 Tray Feeder Zeroing Error (Front)
Traverse zeroing pre-check error
-----
441611 Tray Feeder Zeroing Error (Front)
Pallet chuck CLOSE error
-----
441613 Tray Feeder Zeroing Error (Front)
Pallet chuck OPEN error
-----
441614 Tray Feeder Zeroing Error (Front)
Traverse recede operation error
-----
441615 Tray Feeder Zeroing Error (Front)
The palette was not detected though there was a draw out history.
-----
441616 Tray Feeder Zeroing Error (Front)
Rack shutter OPEN error(Upper Magazine)
-----
441617 Tray Feeder Zeroing Error (Front)
Rack shutter OPEN error(Lower Magazine)
-----
441618 Tray Feeder Zeroing Error (Front)
The other pallet was detected from pallet store position during pulling.
-----
441619 Tray Feeder Zeroing Error (Front)
Traverse zeroing error
-----
4OM-1603
3-65
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
44161a Tray Feeder Zeroing Error (Front)
Pallet chuck CLOSE error
-----
44161b Tray Feeder Zeroing Error (Front)
Rack shutter CLOSE error
-----
44161c Tray Feeder Zeroing Error (Front)
Magazine(Down) Error in shifting Pallet existence detection position.
-----
44161d Tray Feeder Zeroing Error (Front)
Magazine(Up) Error in shifting Pallet existence detection position.
-----
441801 Tray Feeder in advance check error
Tray power supply not turning on(power supply cut off from main machine)
-----
441802 Tray Feeder in advance check error
-----
Please close the body safety cover, and then press "READY" button, lock the
cover.
441803 Tray Feeder in advance check error
Tray maintenance cover OPEN
-----
441804 Tray Feeder in advance check error
Traverse axis main circuit was cut off
-----
441805 Tray Feeder in advance check error
Safety circuit cut off
-----
441806 Tray Feeder in advance check error
Elevator axis main circuit cut off
-----
441807 Tray Feeder in advance check error
Tray Safety Cover(Upper) is open.
Please close Tray safety Cover(Upper), and then press "READY" button, lock the
cover.
441808 Tray Feeder in advance check error
Tray Safety Cover(Center) is open.
Please close Tray safety Cover(Center), and then press "READY" button, lock the
cover.
441809 Tray Feeder in advance check error
Tray Safety Cover(Lower) is open.
Please close Tray safety Cover(Lower), and then press "READY" button, lock the
cover.
44180a Tray Feeder in advance check error
Feeder base is "Ready On"
Please
conrmFeederCartsetcorrectly
,andpressFeederBase"READY"
button.
4OM-1603
3-66
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
44180b Tray Feeder in advance check error
No Magazine(Upper)
Please set Magazine(Upper).
44180c Tray Feeder in advance check error
No Magazine(Lower)
Please set Magazine(Lower).
44180e Tray Feeder in advance check error
Traverse axis Servo Alarm
-----
441810 Tray Feeder in advance check error
Elevator axis Servo Alarm
-----
441811 Tray Feeder in advance check error
Miss-Pickup comp. Detection 8mm[B15417]
-----
441812 Tray Feeder in advance check error
Miss-Pickup comp. Detection 14mm[B15418]
-----
441813 Tray Feeder in advance check error
Miss-Pickup comp. Detection 28mm[B15419]
-----
441814 Tray Feeder in advance check error
Pallet chuck is not shut
-----
441815 Tray Feeder in advance check error
The pallet Miss-Set was detected.
-----
441816 Tray Feeder in advance check error
Magazine(Lower) Rack Shutter on the operator side is open.
-----
441817 Tray Feeder in advance check error
Magazine(Lower) Rack Shutter on the Traverse side is open.
-----
441818 Tray Feeder in advance check error
Magazine(Lower) is not done Positioning yet.
Please
conrmtheMagazinepositionand
Magazinelocklever.
441819 Tray Feeder in advance check error
Elevator axis safety relay
-----
44181a Tray Feeder in advance check error
Magazine(Upper) Rack Shutter on the operator side is open.
-----
44181b Tray Feeder in advance check error
Magazine(Upper) Rack Shutter on the Traverse side is open.
-----
