4OM-1603
3-41
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
425104 Detection of Input conveyor sensor
Stop sensor was Not detected before starting
Placing P.C.B. is not found internal machine.
1. Please put P.C.B. on the sensor
2. Becausethereisa
possibilityofP.C.B.falling,pleaseconrmthewidthof
conveyor.
425105 Detection of Input conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425106 Detection of Input conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Conrmwhetherthesensordoesn’thave
Error.
425107 Detection of Input conveyor sensor
P.C.B. on stop sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425108 Detection of Input conveyor sensor
P.C.B. on stop sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Checkwhetherthesensordoesn’thave
Error.
425109 Detection of Input conveyor sensor
P.C.B. on Input conveyor was detected
Remove P.C.B. from Conveyor.
42510a Detection of Input conveyor sensor
P.C.B. on Input conveyor was not detected
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
42510b Detection of Input conveyor sensor
2 P.C.B. pieces on conveyor exist.
Remove it if unnecessary P.C.B. exists, when checking P.C.B. on Conveyor.
42510c
Detection of Input conveyor sensor
P.C.B. on sensor was detected in the state of not placing P.C.B.
There is a possibility whether P.C.B. is inserted or P.C.B. arrived before detecting
signals.
42510d Detection of Input conveyor sensor
Disengaged P.C.B. of Input conveyor
Possible to driver continuously.
PleaseconrmthestateofP
.C.B.ifitisnotremovedpurposely
42510e Detection of Input conveyor sensor
P.C.B. was not detected when placement was completed
P.C.B. from Input Machine is not received and sent.
PleaseconrmwhetherP.C.B.on
Inputconveyoriscaught.
42510f Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted though the mode that could not be inserted.
Please remove the inserted P.C.B..
4OM-1603
3-42
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
425110 Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted in P-OUT valid mode.
425111 Detection of Input conveyor sensor
There is a possibility of interference between output PCB and input PCB.
PassingPCBoccurredduringsimultaneoustransfer
.Pleaseconrmthatoutputis
running without problems.
425201 Input conveyor timeout
Placement was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the transition with Input Machine.
425202 Input conveyor timeout
Output was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the above conveyor.
425301 Input conveyor Error
Error in Input conveyor
-----
426101 Detection of positioning conveyor sensor
Decrease sensor of input position was detected before starting.
There
isanindeniteP.C.B.
onInputpositiondeceleratingsensor.
Please remove P.C.B..
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
ThereisanindeniteP.C.B.
onInputpositionstopsensor.PleaseremoveP.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after starting.
Thereisan
indeniteP.C.B.
onInputpositiondeceleratingsensor.Pleaseremove
P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426107 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
Thereisan
indeniteP.C.B.
onInputpositionstopsensor.PleaseremoveP.C.B..
4OM-1603
3-43
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
426108 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
Thereisan
indeniteP.C.B.
onOutputpositiondeceleratingsensor.Please
remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
Therei
saninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610c Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610d Detection of positioning conveyor sensor
Decrease sensor of output position was detected after starting.
Therei
saninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
42610e Detection of positioning conveyor sensor
Decrease sensor of output position was not detected after starting.
-----
42610f Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
Thereisaninde
niteP.C.B.onOutputpositionstopsensor.PleaseremoveP.C.B..
426110 Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
Please check whether P.C.B. is detected correctly. Check whether the sensor
doesn’thaveError.
426111 Detection of positioning conveyor sensor
P.C.B. on positioning conveyor was detected
Please remove P.C.B. from positioning conveyor
.
426112 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
ConrmwhetherP.C.B.isnot
dropping.ConrmwhetherSensorisnotbroken.
426113 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
PassingPCBoccurredduringsimultaneoustransfer
.Pleaseconrmthatoutputis
running without problems.
