4OM-1603
2-11
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018209 Multi-tray (Rear)
ZeroingofElevator1-axisisnotnished.
Performzeroingofmulti-tray.
01820a Multi-tray (Rear)
ZeroingofElevator2-axisisnotnished.
Performzeroingofmulti-tray.
01820b Multi-tray (Rear)
Pickup miss cmpnt(8mm) is detected.[B15417]
01820c Multi-tray (Rear)
Pickup miss cmpnt(14mm) is detected.[B15418]
01820d Multi-tray (Rear)
Pickup miss cmpnt(28mm) is detected.[B15419]
01820e Multi-tray (Rear)
Pallet Chuck claw is open.
01820f Multi-tray (Rear)
Pallet Flying away is detected.
018210 Multi-tray (Rear)
Magazine1 (Lower) Shutter on Traverse side is open.
018211 Multi-tray (Rear)
Magazine2(Upper) Shutter on Traverse side is open.
018212 Multi-tray (Rear)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018213 Multi-tray (Rear)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018301 Multi-tray (Front)
Close the safety cover of multi-tray, and press the Ready button).
018302 Multi-tray (Front)
Pallet of multi-tray is drawn out. Execute zeroing all, store the pallet.
018303 Multi-tray (Front)
Multi-tray breaking out was detected. Execute zeroing all, store the pallet.
018304 Multi-tray (Front)
Press [READY] button of Feeder base, and supply the power for Multi Tray.
018305 Multi-tray (Front)
Close the safety cover (Center) of multi-tray, and press [READY] button.
018306 Multi-tray (Front)
Close the safety cover (Lower) of multi-tray, and press [READY] button.
018307 Multi-tray (Front)
Close the safety cover (Upper) of multi-tray, and press [READY] button.
018308 Multi-tray (Front)
Zeroing
ofTraverse-axisisnotnished.
Performzeroingofmulti-tray.
018309 Multi-tray (Front)
ZeroingofElevator1-axisisnotnished.
Performzeroingofmulti-tray.
01830a Multi-tray (Front)
ZeroingofElevator2-axisisnotnished.
Performzeroingofmulti-tray.
01830b Multi-tray (Front)
Pickup miss cmpnt(8mm) is detected.[B15417]
01830c Multi-tray (Front)
Pickup miss cmpnt(14mm) is detected.[B15418]
1012-005
4OM-1603
2-12
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
01830d Multi-tray (Front)
Pickup miss cmpnt(28mm) is detected.[B15419]
01830e Multi-tray (Front)
Pallet Chuck claw is open.
01830f Multi-tray (Front)
Pallet Flying away is detected.
018310 Multi-tray (Front)
Magazine1 (Lower) Shutter on Traverse side is open.
018311 Multi-tray (Front)
Magazine2 (Upper) Shutter on Traverse side is open.
018312 Multi-tray (Front)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018313 Multi-tray (Front)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018401 Multi-tray is not ready to zeroing(Rear)
Execute all zeroing.
018501 Multi-tray is not ready to zeroing(Front)
Execute all zeroing.
018601 Warning of wiring error
Vacuum Pump 1CB Error
018602 Warning of wiring error
Monitor Error of DC load power
018603 Warning of wiring error
Monitor Error of Beam(1) CB Error
018604 Warning of wiring error
Monitor Error of Beam(2) CB Error
018701 Feeder Alternate
Illegal alternate setup of pattern program. Check the setup.
018702 Feeder Alternate
Invalid feeder in alternating. Set feeder valid
018801 XY Origin Offset
Illegal XY-Origin offset of Beam(Rear). Re-send Device data from NT, or execute
teaching XY-Origin offset.
018802 XY Origin Offset
Illegal XY-Origin offset of Beam(Front). Re-send Device data from NT, or execute
teaching XY-Origin offset.
018901 Feeder communication
Feeder(Rear) is on communication. Please wait for it, and then operate again.
018902 Feeder communication
Feeder(Front) is on communication. Please wait for it, and then operate again.
018a01 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Rear)
018a02 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Front)
018b01 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Rear)
4OM-1603
2-13
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018b02 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Front)
019001 Support Pin
Please move exchange position of support pin.
019002 Support Pin
Noz for enchasing support pin is not set, or Odd-shape noz is set.
019003 Support Pin
Placement data in current differs from it of Support Pin of current pattern program.
Please set-up the support pin.
019004 Support Pin
When PCB size 216mm is exceeded, it is impossible to operate if Support pins of
Lane A remain. Please exchange Lane A, or take out it from machine.
019005 Support Pin
It is impossible to do operation for only Lane B because Support Pins of Lane A
remain. Please exchange Lane A, or take out it from machine.
019006 Support Pin
Operation for Lane A is impossible because Support Pins of Lane A have not been
installed. Please exchange Support pins or store them.
019007 Support Pin
It is impossible to do Operation for only Lane A because Support Pins of Lane B
remain. Please exchange Lane B, or take out it from machine.
019008 Support Pin
Support pins of Lane B remain on the base for Support pins of Lane A, so that it is
impossible to do Conveyor width. Please exchange Support pins or store them.
019009 Support Pin
Arrangement of Support Pins interferes in Conveyor. Please retry to arrange it.
030162 Operation Requirement
The pattern cannot be switched
030413 Operation Requirement
Specify the order No.
030416 Operation Requirement
ACV server does not pass the authorization. Please retry connection to server on
a screen [UNIT ADJ]-[ACV Set].
03041c Operation Requirement
ACV
CheckError.ComponentID
onthefeederisnotsameasonespeciedby
current program.
030420 Operation Requirement
CommunicationswiththeACVserveris
impossible.AfterconrmingtheACV
server, please try to perform it again in the tab sheet: [MAINT]-[UNIT ADJ]-[ACV
ADJ].
030430 Operation Requirement
Can not detect Feeder cart(Rear). Please set Feeder cart to the inside.
[B0910, B0911]
030431 Operation Requirement
Can not detect Feeder cart(Front). Please set Feeder cart to the inside.
[B0910, B0911]
1012-005
