4OM-1603 3-136 3. Error IDs and Remedial Procedures : Chap.3 Error ID Error Name, Description, Cause, and Remedy 602503 T eaching T ray Matrix T ime-out in XY -axis movement ----- 602504 T eaching T ray Matrix Error in M…
4OM-1603
3-135
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
602212 Teaching Pulling Traverse
Recognition Performance Time-out
-----
602213 Teaching Pulling Traverse
Error of P.C.B. Recognition Lamp Off
-----
602214 Teaching Pulling Traverse
Time-out of P.C.B. Recognition Lamp Off
-----
602215 Teaching Pulling Traverse
Error of Origin position calculation
-----
602216 Teaching Pulling Traverse
Program Error
-----
602301 Teaching Tray Pick-up position
Error of teaching tray pick-up position
-----
602302 Teaching Tray Pick-up position
Error of XY-axis movement
-----
602303 Teaching Tray Pick-up position
Time-out in XY-axis movement
-----
602304 Teaching Tray Pick-up position
Error in Manual Teach
-----
602401 Teaching correction of Pick-up position
Error in teaching correction of Pick-up position
-----
602402 Teaching correction of Pick-up position
Error of XY-axis movement
-----
602403 Teaching correction of Pick-up position
Time-out in XY-axis movement
-----
602404 Teaching correction of Pick-up position
Error in Manual Teach
-----
602501 Teaching Tray Matrix
Error of teaching coplanarity.
-----
602502 Teaching Tray Matrix
Error of XY-axis movement
-----
1012-005
4OM-1603
3-136
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
602503 Teaching Tray Matrix
Time-out in XY-axis movement
-----
602504 Teaching Tray Matrix
Error in Manual Teach
-----
602601 Teaching Coplanarity
Error of teaching coplanarity.
-----
602602 Teaching Coplanarity
Recognition Error
-----
602603 Teaching Coplanarity
Timeout of communication with Coplanarity unit
-----
602701 Teaching Table Offset
Error in Table Offset Teach
-----
602702 Teaching Table Offset
Error of Recognition Command Response. Is P.C.B. taken in correctly?
Please check it.
-----
602801 Teaching position of Support Pin
Error in teaching position of Support Pin
-----
602802 Teaching position of Support Pin
Error in responding Recog command
-----
602803 Teaching position of Support Pin
Time-out of Communication with Recog
-----
602804 Teaching position of Support Pin
Position Offset of Support Pin is out of the permissible value.
-----
602901 -----
-----
-----
602902 -----
-----
-----
602903 -----
-----
-----
602904 -----
-----
-----
1012-005
4OM-1603
3-137
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
602905 -----
-----
-----
602906 -----
-----
-----
602907 -----
-----
-----
602908 -----
-----
-----
603001 XY Origin teach
Failed to recognize Origin Correction Mark
Modify the teaching position and execute teaching again.
604001 Automatic Teaching on producing operation.
Failed to recognize a nozzle in Head rotation center offset teaching.
-----
604002 Automatic Teaching on producing operation.
Error in recognition command response in Head rotation center offset teaching.
-----
604003 Automatic Teaching on producing operation.
Could not recognize the Standard Mark.
-----
604101 Teaching Placement-Height
Error is detected before starting Detection on the Linear Sensor.(There is a
possibility that the Linear measure Sensor is broken , or Odd Noz is placed)
-----
604102 Teaching Placement-Height
Time-out of [OFF] signal of Linear measure sensor
-----
604103 Teaching Placement-Height
Error in DD-axis
-----
604104 Teaching Placement-Height
Error in NS-axis
-----
604105 Teaching Placement-Height
Error in DD/NS-axis
-----
604106 Teaching Placement-Height
Time-out of DD/NS-axis
-----
604107 Teaching Placement-Height
Error in calculating drive wave of HL-axis
-----
1012-005
