4OM-1603
3-100
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b031D Feeder Base
Cart rising stopped(Rear). Cannot release the safety cover for the cart in the
opposite side is in process. the process stopped because there is a possibility
that something is placed between Cart and the safety cover.
-----
4b031E Feeder Base
Cart rising stopped(Front). Cannot release the safety cover for the cart in the
opposite side is in process. The process is stopped because there is a possibility
that something is placed between Cart and the safety cover.
-----
4b031F Feeder Base
Failed that Automatic safety cover opening starts up. The process is stopped
because there is a possibility that something is placed between Cart and the
safety cover.
-----
4b0320 Feeder Base
Automatic safety cover opening is not completed in predetermined time. The
process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0321 Feeder Base
Failed in Automatic safety cover opening (Release Lock).
The process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0501 Manual alignment Error
Operation was not completed within predetermined time.
-----
4b050f Manual alignment Error
Error was detected during operation.
-----
4b0701 Connection Error.
Failed in communications with the Control CPU.
-----
4b0702 Connection Error.
Failed in communications with the Recog. CPU.
-----
4b0801 Linear measure operation is abnormal.
Linear measure was found abnormality while measuring.
There
isapossibilityofLight
EmitterandReceiverbroken.PleaseconrmError
from Log Request Screen(Unit adjustment -> Linear measure Sensor Screen)
4b0802 Linear measure operation error
The measurement by the linear measure sensor was not completed on time.
Communication connector of Linear measure Sensor P.C.B is taken off. Please
conrmwhethertheitemsofLS-RLS-S(Device
Check->List)isYellow.HLS
communication cable could not be connected and such like things.
4OM-1603
3-101
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b0803 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
LightEmitterandReceivercouldhave
awandsoil.Pleasecleanitup.Please
press [Operation] on the screen(Unit adjustment -> Linear measure Sensor ->
DetectiontestScreen)andconrmwhether
thereisanerror
4b0804 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
There is a possibility of Line Sensor P.C.B. broken
4b0805 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
A small light quantity of Light Emitter. Please exchange Light Emitter.
4b0806 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
There is a possibility of Line Sensor P.C.B. broken. Either, Please update Version
on the screen(Unit adjustment -> Linear measure Sensor -> Correct data read
Screen)
4b0807 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
PleaseconrmErrorfromLogRequest
Screen(Unitadjustment->Linear
measureSensorScreen).Either,pleaseconrmwhethertheitemsofLS-RLS-
S(Device Check -> List) is Yellow.
HLS communication cable could not be connected and such like things.
4b0808 Linear measure operation error
There is a problem in the values measured by the linear measure sensor.
PleaseconrmErrorfromLogRequest
Screen(Unitadjustment->Linear
measureSensorScreen).Either,pleaseconrmwhethertheitemsofLS-RLS-
S(Device Check -> List) is Yellow.
HLS communication cable could not be connected and such like things.
4b0809 Linear measure operation error
There is a problem in the linear measure Sensor.(Strobe Signal did not turn off
within predetermined time.)
PleaseconrmErrorfromLogRequest
Screen(Unitadjustment->Linear
measureSensorScreen).Either,pleaseconrmwhethertheitemsofLS-RLS-
S(Device Check -> List) is Yellow.
HLS communication cable could not be connected and such like things.
4b0c01 NozzleConrmationErrorbeforepickup
compDetectAfterPlacement)
Because a component was found on a nozzle, it stopped after disposal.
The result could have some problems.
Please check placement state on placement step recovery screen.
4b0c02 NozzleConrmationErrorbeforepickup
comp
The remains component was found on a nozzle during production.
PleaseconrmwhetherthereisanerrorintheP.C.B.
4b0c03 NozzleConrmationErrorbeforepickup
compDetectAfterDiscard
Because a component was found on a nozzle, it stopped after disposal.
Pleaseconrmandcleanupthenozzleifthiserrorcontinues.
4OM-1603
3-102
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b0e01 Splicing tape set error
The joint part of splicing tape is not correctly set. Please extract a feeder and
check whether the tape has separated from the guide.
4b1201 Press in error / Insertion error
There is an error with the component pressed in or Insertion
Opensafetycoverandconrmthe
componentonP.C.B.Pleaseremoveitor
revise it
4b2001 P.C.B Height Measurement
Abnormal measured value was detected.
Check the measurement position.
4b2002 P.C.B Height Measurement
Abnormality occurred for communication with a sensor
-----
4b2003 P.C.B Height Measurement
The abnormality number of times of measured value was beyond a set point.
Running is stopped.
-----
4b2004 P.C.B Height Measurement
The abnormality number of times of measured value was beyond a set point.
-----
4b2005 P.C.B Height Measurement
A measurement result is abnormal(measure in arbitrary position)
Check the measurement position.
4b2006 P.C.B Height Measurement
Surpass a measurement range. (+ direction)
-----
4b2007 P.C.B Height Measurement
Surpass a measurement range. (- direction)
-----
4b2008 P.C.B Height Measurement
Detected a curve more than permission values. (+ direction)
-----
4b2009 P.C.B Height Measurement
Detected a curve more than permission values. (- direction)
-----
4b200a P.C.B Height Measurement
Error of the result measured by a master jig (height)
Check if the master jig (height) has some dirt and foreign particles.
4b200b P.C.B Height Measurement
Failed in wearing height revision.
-----
4b200c P.C.B Height Measurement
An abnormal measurement was detected by the multipoint measurement.
Check the measurement position.
