4OM-1603

3-23

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

42011e Backup(L) Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42011f Backup(L) Error

System Error of Backup(L) axis

System Error of internal driver. Driver error is supposed if this problem happens

frequently.

420120 Backup(L) Error

Communication Error of the Backup(L) axis

1. Conrmconnectiontocommunicationcable.

2. Conrm

Powersupply(24V).

3.ConrmthecommunicationsettingofPCIboard.

4. Conrmtheaddressofdriverandcommunicationratesetting.

420201 Backup(R) Axis Error

The Backup(R) Axis was not completed within predetermined time.

Backup axis is unable to do upward movement and down movement.

The factor is for Motor, Driver, Sensor Error or wiring Error.

Please check the motor, sensor on Machine check screen.

420202 Backup(R) Axis Error

Driver Alarm on Backup(R) Axis

ConrmresetMethodofdetailedSub-system

errorcountsofAlarm.

420203 Backup(R) Axis Error

Error in calculating data of positioning command of Backup(R) Axis

Pleaseconrmthefollowingdata.

1. Machine Offset/Backup Pin(Up/Down)

Pattern Program/P.C.B. Information/P.C.B. size/Thickness

3. Control/Common/PRE-PLACED CMPNT THKNS/Bottom of P.C.B.

420204 Backup(R) Axis Error

Time-over of zeroing of Backup(R) Axis

Check out the dirt, error, disconnection of sensor. If there is no problem with

sensor, the problem could be with motor wire/single error.

420205 Backup(R) Axis Error

Time-over of the upward movement of stopper(R)

1. PleaseconrmwhetherP.C.B.is

caughtbetweenstopperandconveyor.

2. Error in Up/Down detecting sensor. Please check sensor input.

3. Disconnection/ErrorofOutput.Pleaseconrmthestopperbymanualifsensor

input is correct.

4. Please reset the speed by adjusting speed control when stopper is slow.

420206 Backup(R) Axis Error

Time-over of the downward movement of stopper(R)

1. Errorin

Up/Downdetectingsensor.

Conrmthesensor.

2. Disconnection/ErrorofOutput.Pleaseconrmthestopperbymanualifsensor

input is correct.

3. Please reset the speed by adjusting speed control when stopper is slow.

4OM-1603

3-24

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

420207 Backup(R) Axis Error

Communication Error of the command movement of P.C.B. positioning(Backup)

Motor Driver Error Trouble in communication system(AE-LINK), possibility of Error

of communication P.C.B.(API).

Pleaseconrmwiringofcommunicationline

andPowerline.

420208 Backup(R) Axis Error

Backup Pin/Jig under the conveyor belt is detected.

Check out the interference in Belt on Backup Base does not exist.

420210 Backup(R) Axis Error

Not ready for System setup of Backup(R) axis

Driver has not completed the parameter setup yet. It is a situation in which a

correct setup has not been received by Communication Error.

Check the Communication Mode, wiring, Power supply of Driver.

420211 Backup(R) Axis Error

Error in zeroing in Backup(R) axis

LS, discontinuous zeroing movement, was detected.

Check out the dirt, error of sensor and error in Motor body etc.

420212 Backup(R) Axis Error

Out-of-Control of Backup(R)

Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.

Please execute all zeroing again, and the restart production.

Please set motor speed slow if it happens frequently. Also, in a case of structure

motor Error.

420213 Backup(R) Axis Error

Error in motor power voltage of Backup(R) axis

Motor power voltage dropped. Check out the Power supply line(48V Line)

420214 Backup(R) Axis Error

STP input of Backup(R) Axis is detected

STP input is detected. The function to stop motor by Hard signal.

420215 Backup(R) Axis Error

Over-current of Backup(R) Axis

Abnormal current in motor output line was detected.

Conrm

themotorwiring,supplyingpower

420216 Backup(R) Axis Error

Limit Sensor(+) of Backup(R) axis is detected

+LS signal was detected for moving for (+).

Please check the dirt of +LS sensor, disconnection.

420217 Backup(R) Axis Error

Limit Sensor(-) of Backup(R) axis is detected

-LS signal was detected for moving for (-).

Please check the dirt of -LS sensor, disconnection.

420218 Backup(R) Axis Error

Disconnection Motor of Backup(R) axis is detected

Disconnection to motor was detected.(Only stop mode)

Check the motor wiring.

4OM-1603

3-25

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

420219 Backup(R) Axis Error

Error in the Control Power Voltage of Backup(R) axis

Control power for driver dropped. Check out the Power supply line.(24V Line)

42021a Backup(R) Axis Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42021b Backup(R) Axis Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42021c Backup(R) Axis Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42021d Backup(R) Axis Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42021e Backup(R) Axis Error

-----

Reserved Function of driver. Please make inquiries when error is detected.

42021f Backup(R) Axis Error

System Error of Backup(R) axis

System Error of internal driver. Driver error is supposed if this problem happens

frequently.

420220 Backup(R) Axis Error

Communication Error of the Backup(R) axis

1.

Conrmconnectiontocommunicationcable.

2. Conrm

Powersupply(24V).

3. ConrmthecommunicationsettingofPCIboard.

4. Conrmtheaddressofdriverandcommunicationratesetting.

420301 A-lane Backup(L) Axis

-----

420401 A-lane Backup(R) Axis

-----

420501 B-lane Backup(L) Axis

-----

420601 B-lane Backup(R) Axis

-----

421001 Error in Transfer section

Transfer operation was not completed within predetermined time.

-----

421002 Error in Transfer section

(At

nishingAutoRun)Transferoperation

wasnotcompletedwithinaspecied

time.

Please push Emergency Stop button
