4OM-1603
2-22
3. Machine Information : Chap.2
3.2 Machine Information List
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
800301 Warning: Decreasing of Comp. Hdlg. Rate(For Nozzle.)
Nozzle message rate :
-----
800302 Warning: Decreasing of Comp. Hdlg. Rate(For Nozzle.)
The rate of nozzle adsorption fell. A cycle stop is carried out.
-----
800401 Warning: Decreasing of Comp. Hdlg. Rate(For Fdr.)
Feeder message rate :
-----
800402 Warning: Decreasing of Comp. Hdlg. Rate(For Fdr.)
The rate of nozzle adsorption fell. A cycle stop is carried out.
-----
800505 Alternated Tray Magazine Axis
Shortage of component
-----
800601 Alternated Feeder
Shortage of component
-----
800602 Alternated Feeder
Splice waiting
-----
800603 Alternated Feeder
Comp. Vertical(sensor)
-----
800604 Alternated Feeder
Comp. Thickness(sensor)
-----
800605 Alternated Feeder
Comp. Missing(sensor)
-----
800606 Alternated Feeder
Comp. Recog. Error(recog.)
-----
800607 Alternated Feeder
Comp. Missing(recog.)
-----
800608 Alternated Feeder
Coplanarity Check Error
-----
800609 Alternated Feeder
The feeder at the alternation destination is invalid. Please set it effectively.
-----
1012-005
4OM-1603
2-23
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80060a Alternated Feeder
Feeder unloading
-----
800801 Start Auto Recovery Mode
Shortage of component
-----
800802 Start Auto Recovery Mode
Splice waiting
-----
800803 Start Auto Recovery Mode
Comp. Vertical(sensor)
-----
800804 Start Auto Recovery Mode
Comp. Thickness(sensor)
-----
800805 Start Auto Recovery Mode
Comp. Missing(sensor)
-----
800806 Start Auto Recovery Mode
Comp. Recog. Error(recog.)
-----
800807 Start Auto Recovery Mode
Comp. Missing(recog.)
-----
800808 Start Auto Recovery Mode
Coplanarity Check Error
-----
800809 Start Auto Recovery Mode
Feeder Alarm
-----
80080a Start Auto Recovery Mode
Feeder unloading
-----
80080b Start Auto Recovery Mode
Device Op is stopped because Feeder is not loaded.
-----
80080c Start Auto Recovery Mode
Etc
-----
800902 Alarm for Shortage of Comp.
Few components to feed.
-----
1012-005
4OM-1603
2-24
3. Machine Information : Chap.2
1012-005
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
801101 Nozzlediameterconrmation
The disagreement of the nozzle diameter was detected with the linear measure.
Thereisapossibility
ofthelinearmeasuredirtandthenozzledirt,pleaseconrm
whether a different nozzle has adhered.
-----
801b01 Lightning Surge alarm
Lightning Surge Protector works; Q204.
-----
801b02 Lightning Surge alarm
Lightning Surge Protector works; Q204. Running continue.
-----
801b03 Lightning Surge alarm
Protective Fuse error of lightning Surge Protector. Exchange the fuse.
-----
801c05 Information
Warm start mode was canceled.
-----
801c06 Information
The machine stopped by the automatic stop function.
-----
802001 Alarm for Splicing
The feeder is running short of the component to feed.
Please prepare for Splicing, and remove the cover tape from the storage section.
-----
802101 Feeder Maintenance alarm
The total number of feeder's shots reached a previous notice setting number.
-----
802102 Feeder Maintenance alarm
The feeder adsorption rate decreased and exceeded the previous notice setting
number.
-----
802201 ACV Information
ACV
CheckError.ComponentID
onthefeederisnotsameasonespeciedby
current program.
-----
802202 ACV Information
Device(Rear) Cannot clear Clamp for feeder communication. Please operate it
again later.
-----
802203 ACV Information
Device(Front) Cannot clear Clamp for feeder communication.
Please operate it again later.
-----
