4OM-1603
3-119
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
511209 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AL) is abnormal.
-----
511210 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AR) are detected
simultaneously.
-----
511211 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AR) is abnormal.
-----
511212 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AR) is abnormal.
-----
511213 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BL) are detected
simultaneously.
-----
511214 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BL) is abnormal.
-----
511215 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BL) is abnormal.
-----
511216 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BR) are detected
simultaneously.
-----
511217 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BR) is abnormal.
-----
511218 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BR) is abnormal.
-----
511301 Added squeeze error
Added squeeze is not completed.
Open the safety cover and check the placed components. Then, please remove
or revise them.
T4C14
1012-005
4OM-1603
3-120
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600101 P.C.B. recog camera & beam offset teach.
-----
-----
600102 P.C.B. recog camera & beam offset teach.
Error of Recognition Command response.
-----
600103 P.C.B. recog camera & beam offset teach.
Error of coordinates calculation.
-----
600104 P.C.B. recog camera & beam offset teach.
Error of Data set for XY Beam.
-----
600105 P.C.B. recog camera & beam offset teach.
Error of moving for XY Beam.
-----
600106 P.C.B. recog camera & beam offset teach.
Time-out in XY Beam
-----
600107 P.C.B. recog camera & beam offset teach.
Time-out of communication with recognition.
-----
600108 P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on parts recognition camera.
-----
600109 P.C.B. recog camera & beam offset teach.
Recognition failure of checker on reference pin.
-----
60010a P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on glass jig.
-----
600201 Comp. Recog. Camera offset teach.
The glass Jig can not able to be recognized.
Please check that Glass Jig is right on Glass Jig place(Check it because there is
a possibility that nozzle is not on head, or vacuum is not "ON")
600202 Comp. Recog. Camera offset teach.
-----
600203 Comp. Recog. Camera offset teach.
Error of Recognition command response.
-----
600204 Comp. Recog. Camera offset teach.
Error of coordinates calculation.
-----
600205 Comp. Recog. Camera offset teach.
Error when Jig pickup started
-----
4OM-1603
3-121
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
600206 Comp. Recog. Camera offset teach.
Error in the movement of Jig pickup
-----
600207 Comp. Recog. Camera offset teach.
Error when Jig began to be stored
-----
600208 Comp. Recog. Camera offset teach.
Error in the movement of Jig stored
-----
600209 Comp. Recog. Camera offset teach.
Error when HL-axis began to drop.
-----
60020a Comp. Recog. Camera offset teach.
Error when HL-axis began to rise.
-----
60020b Comp. Recog. Camera offset teach.
Error of Data set for XY Beam.
-----
60020c Comp. Recog. Camera offset teach.
Error of moving for XY Beam.
-----
60020d Comp. Recog. Camera offset teach.
Time-out of moving for XY Beam.
-----
60020e Comp. Recog. Camera offset teach.
Time-out of communication with recognition.
-----
600301 Head Rotate Theta Axis offset
Could not recognize Nozzle
Is Nozzle placed? Is right Nozzle position data set? Please check them.
600302 Head Rotate Theta Axis offset
Error of Recognition Command response.
-----
600303 Head Rotate Theta Axis offset
Could not recognize the section of nozzle shaft
-----
600304 Head Rotate Theta Axis offset
Error of coordinates calculation.
-----
600305 Head Rotate Theta Axis offset
Error when DD-axis began to rotate.
-----
600306 Head Rotate Theta Axis offset
Error during rotation of DD-axis
-----
