4OM-1603
3-113
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b4204 Feeder Alarm
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4205 Feeder Alarm
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponents
anddustarebeingcaughtinthetape
feeding gear.
4b4301 Feeder Section(Miss-pickup)
A pickup error occurred due to feeder operation problem.
Please check the feeder and the component.
-----
4b4401 ErrorinconrmingconnectionofFeeder
Error
inconrmingconnectionofFeeder
Please check connection of Feeder
4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b4601 Feeder error (feeding time-out)
Feeder error (feeding time-out)
-----
4b4701 SV-NET Communication
Internal Error.
Please restart the machine.
4b4801 2D bar code Time-out
Time-out of Sequence
-----
4b4802 2D bar code Time-out
Time-out of Communication
-----
4b4901 Feeder Feeding Pitch Correction Error
Feeder Feeding Pitch is out of position, but Auto Correction for it failed.
Please do teaching pick-up position.
4b4a01 Recycle Conveyor is taken off.
Do not take off Recycle Conveyor, please.
-----
4b4a02 Recycle Conveyor is taken off.
There is a possibility that Noz bent. Do not take off Recycle Conveyor during
Disposal.
Please
opentheCover,then
conrmwhetherNozdidnotbend.
1012-005
4OM-1603
3-114
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b4b01 Cutter Error
(AtnishingAutoRun)Cutteroperation
(Rear)isnotcompletedwithinaspecied
time.
Please push Emergency Stop button.
4b4b02 Cutter Error
(AtnishingAutoRun)Cutteroperation(Front)
isnotcompletedwithinaspecied
time.
Please push Emergency Stop button.
4b4c01 Flux dispensing Error
Flux dispensing sequence error
-----
4b4c02 Flux dispensing Error
Cannotdetectcomponentsexistenceafterdispensing
ux.Errorinuxsensor.
-----
4b4d01 Flux dispensing unit Error
Flux dispensing Unit stopped in emergency.
-----
4b4d02 Flux dispensing unit Error
Flux dispensing Unit is not set.
Pleasesetuxdispensingunitto
thedeterminedplace.
4b4d03 Flux dispensing unit Error
Motor alarm.
Pleasedetachuxdispensingunit,and
conrmwhetherthereisafactorofload
or not.
4b4d04 Flux dispensing unit Error
Flux dispensing was not completed within predetermined time.
1.Pleaseconrmrotationwith[rotation]
button.
2.Pleaseconrmwhetherthevolumeofrotaryspeedisnot"0".
3.PleaseconrmwhetherRotationPhotosensorisresponsive.
4.Pleaseconrmwhethertimingbelthassomeproblems.
4b4e01 Flux material shortage
Nouxonthedrum.Please
supplyFlux.
-----
4b4f01 Nocmpntafterux
dispensing(Sensor)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Pleasedetachuxdispensingunit,andthenremovecomponentsonthedrum.
4b5001 Nocmpntafteruxdispensing(Recog)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Please
detachuxdispensingunit,andthenremovecomponentsonthedrum.
4b5101 Recycle conveyor error
It was impossible to detect the Cmpnt passing the passing check sensor.
Please remove all the components on the recycle conveyor.
4b5201 Impossible disposal(Disposal box)
It is impossible to send cmpnt to disposal box for discard because it is too large.
Please carry out disposal after inserting the recycle conveyor.
4OM-1603
3-115
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
4b5301 Disposal error
Error in the disposal
Please retry to dispose. Please remove the cmpnt in the head and restart up if
there is still an error.
