4OM-1603
3-72
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.7 PEC Recognition
Error ID Error Name, Description, Cause, and Remedy
460101 P.E.C. Inspection
P.E.C. Mark #1 (Global)
-----
460102 P.E.C. Inspection
P.E.C. Mark #2 (Global)
-----
460103 P.E.C. Inspection
P.E.C. Mark #3 (Global)
-----
460104 P.E.C. Inspection
P.E.C. Mark #1 (Image)
-----
460105 P.E.C. Inspection
P.E.C. Mark #2 (Image)
-----
460106 P.E.C. Inspection
P.E.C. Mark #3 (Image)
-----
460107 P.E.C. Inspection
P.E.C. Mark #1 (Local)
-----
460108 P.E.C. Inspection
P.E.C. Mark #2 (Local)
-----
460109 P.E.C. Inspection
P.E.C. Mark #3 (Local)
-----
46010a P.E.C. Inspection
Land P.E.C. Mark #1
-----
46010b P.E.C. Inspection
Land P.E.C. Mark #2
-----
46010c P.E.C. Inspection
Land P.E.C. Mark #3
-----
46010d P.E.C. Inspection
Failed in P.E.C. Recognition
Please perform to the following
1.
Repeat P.C.B. positioning
2. ConrmwhethertheMark
positionofP.C.B.Recognitioniscorrect.
4OM-1603
3-73
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
46010e P.E.C. Inspection
Failed in Land recog
Please perform methods to the following.
1. Check Mark on the PCB
2. Revise PCB positioning
460201 2D bar code Error
Failed in reading 2D bar code
Please perform to the following
1. The condition of PCB Positioning
2. Specify the position of 2D bar code
3. Detect the dirty of 2D bar code
T4C9
1012-005
4OM-1603
3-74
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
490603 Conveyor Width Automatic Adjustment
PCB exists on the L conveyor.
-----
490604 Conveyor Width Automatic Adjustment
PCB exists on the R conveyor.
-----
490617 Conveyor Width Automatic Adjustment
Software limit
-----
490690 Conveyor Width Automatic Adjustment
Auto Setup Error(Others).
-----
490701 Nozzle set up
Nozzle Stocker is not set.
Please check whether it is correctly set to the stocker base.
490702 Nozzle set up
Motor Error Detection.
-----
490703 Nozzle set up
Nozzle Stocker Shutter open/close failed.
Thereisnooatgoingup
ofanozzle,orpleasecheckwhetherthereisany
connection etc. in opening and closing.
490704 Nozzle set up
The up/down movement of Nozzle Stocker failed.
PleaseconrmwhetherUpper/LowerCylinderhas
noerror.
490705 Nozzle set up
Nozzle placing was not found in the stocker.
Check whether there is any difference in stocker arrangement data and real
arrangement.
490707 Nozzle set up
Thereisnofreespacefor
nozzlestoring.Pleaseconrmthearrangementdata.
PleaseconrmtheStockerarrangementdata.
490708 Nozzle set up
There are neither a free space nor a nozzle for nozzle exchange.
Pleasesetupaninsufcientnozzle
inNozzlestocker.
490709 Nozzle set up
Nozzle exchange abnormal data was found.
Pleaseconrmthenozzlearrangementand
theStockerarrangementdata.
49070a Nozzle set up
Nozzle stocker position teaching failed.
Please teach the Nozzle stocker position again on the instruction screen.
49070c Nozzle set up
Nozzle level teach error Detection.
Please execute the nozzle level teaching again on the nozzle level teach screen,
andconrmthereisnounexpected
value.
