Safety Precautions Safe-24 1OM-1603 1003-003 4. Alert Labels Alert Labels and Description No. Alert Labels and Description (1) Description Strong permanent magnets are used in the moving mechanisms of the X/Y beam. Tho…
Safety Precautions
Safe-23
1OM-1603
4. Alert Labels
(9)
High-Speed Head
Multi-Functional Head
(16)
(9)
F1X9
1012-004
Safety Precautions
Safe-24
1OM-1603
1003-003
4. Alert Labels
Alert Labels and Description
No. Alert Labels and Description
(1)
Description
Strong permanent magnets are used in the moving mechanisms of the X/Y beam.
Those who wear implanted pacemakers should not work inside the machine.
The pacemaker may be affected by magnetism, causing a serious accident.
(2)
Description
Permanent magnets are used in the tape feeding and cover tape take-up sections of
the tape feeder.
Do not allow any person who wears an implanted pacemaker to handle the tape
feeders. Otherwise, the pacemaker may be affected by magnetism, causing a serious
accident.
(3)
Description
When maintenance or checks are performed, make sure to turn off the power to the
machine or air source. When maintenance or checks are performed with the power
or air turned ON, an electric shock or injury might be caused.
Safety Precautions
Safe-25
1OM-1603
1012-004
4. Alert Labels
No. Alert Labels and Description
(4)
Description
Only well-trained service personnel shall replace the cutter blades. Otherwise, a
hand injury, etc., will result.
(5)
Description
This label indicates that high voltage is applied to the area. Residual voltages may
remain behind for a few minutes in the internal devices of the machine after power
interception.
Before performing maintenance work, wait until the charge lamps of the DC power
supply and the servo amplier go "OFF" in 10 minutes or more after the power
breaker is set to "OFF".
(6)
Description
Before connecting to the breaker's primary power leading-in section, connect the
grounding cable (PE).
Imperfect grounding will cause an electric shock.
