4OM-1603

3-39

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

423607 Error in NR-L2 axis

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

423608 Error in NR-L2 axis

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

423609 Error in NR-L2 axis

System Error on NR-L1 axis

System Error of internal driver. Driver error is supposed if this problem happens

frequently.

42360a Error in NR-L2 axis

Communication Error on NR-L1 axis

1. Conrmconnectiontocommunicationcable.

2. Conrm

Powersupply(24V).

3. ConrmthecommunicationsettingofPCIboard.

4. Conrmtheaddressofdriverandcommunicationratesetting.

5. ConrmFirmwareofDriver.

42360b Error in NR-L2 axis

Zeroing Error on NR-L2 axis

No use the function. Please check the driver-axis setting when error is detected

because there is a possibility of error of driver-axis setting.

42360c Error in NR-L2 axis

Out-of-Control of NR-L2 axis was detected

No use the function. Please check the driver-axis setting when error is detected

because there is a possibility of error of driver-axis setting.

42360d Error in NR-L2 axis

Error in motor power voltage of NR-L2 axis

Motor power voltage dropped. Check out the Power supply line(48V Line)

42360e Error in NR-L2 axis

STP input on NR-L2 axis was detected

STP input is detected. The function to stop motor by Hard signal.

42360f Error in NR-L2 axis

Over-current in NR-L2 axis

Abnormal

currentinmotoroutputline

wasdetected.Conrmthemotorwiring,

supplying power.

423610 Error in NR-L2 axis

Communication Error on NR-L2 axis

1. Conrmconnectiontocommunicationcable.

2. Conrm

Powersupply(24V).

3. ConrmthecommunicationsettingofPCIboard.

4. Conrmtheaddressofdriverandcommunicationratesetting.

5. ConrmFirmwareofDriver.

424001 Stopper movement Error

Stop sensor was detected before positioning(R) stopper

ThereisapossibilitythatP

.C.B.ispulledandraisedinStopper.Pleaseconrm

P.C.B. stopping position.

4OM-1603

3-40

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

424002 Stopper movement Error

Positoning(R) stopper was not completed within predetermined time.

1. Check out the P.C.B. between stopper and conveyor

2. Error in Up/Down detection sensor. Check out the sensor input

3. Disconnection, Error of Movement output. Please check Stopper by manual

movement if sensor input is proper.

4. Please set speed again by adjusting speed control when stopper is slow.

424003

Stopper movement Error

P.C.B. was detected on Stopper.

P.C.Bis

stoponthe

Stopper.PleaseconrmwhetherConveyorhasnoError.

424101 Detection of Input conveyor P.C.B.

P.C.B. was detected before starting placement from input machine

PleaseremoveindeniteP.C.B.from

conveyor.ConrmwhetherP.C.B.isnot

detected before P.C.B. transfer.

424102 Detection of Input conveyor P.C.B.

P.C.B. on Input conveyor is existing

Remove P.C.B. from Conveyor.

424201 Detection of output conveyor P.C.B.

P.C.B. was detected before starting output for output machine

Remove P.C.B. from Conveyor.

424202 Detection of output conveyor P.C.B.

The output for Output machine is completed, but P.C.B. on conveyor was detected

Remove P.C.B. from Conveyor.

424301 Detection of positioning conveyor(R) P.C.B.

No P.C.B. on conveyor

Output

P.C.B.isnotdetected.

PleaseconrmwhetherP.C.B.isdetectedcorrectly

or not.

424302 Detection of positioning conveyor(R) P.C.B.

The placement was completed, but P.C.B. was not detected.

PlacedP.C.B.isnotdetected.

PleaseconrmwhetherP.C.B.isdetectedcorrectly

or not.

425101 Detection of Input conveyor sensor

Decrease sensor was detected before starting

Remove P.C.B. from Input Conveyor.

425102 Detection of Input conveyor sensor

Decrease sensor was not detected before starting

Placing P.C.B. is not found internal machine.

1. Please put P.C.B. on the sensor

2. Becausethereisa

possibilityofP.C.B.falling,pleaseconrmthewidthof

conveyor.

425103 Detection of Input conveyor sensor

Stop sensor was detected before starting

Remove P.C.B. from Input Conveyor.

4OM-1603

3-41

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

425104 Detection of Input conveyor sensor

Stop sensor was Not detected before starting

Placing P.C.B. is not found internal machine.

1. Please put P.C.B. on the sensor

2. Becausethereisa

possibilityofP.C.B.falling,pleaseconrmthewidthof

conveyor.

425105 Detection of Input conveyor sensor

P.C.B. on decrease sensor was detected after movement completion

Remove P.C.B. from Input Conveyor.

425106 Detection of Input conveyor sensor

P.C.B. on decrease sensor was not detected after movement completion

Please check whether P.C.B. is detected correctly.

Conrmwhetherthesensordoesn’thave

Error.

425107 Detection of Input conveyor sensor

P.C.B. on stop sensor was detected after movement completion

Remove P.C.B. from Input Conveyor.

425108 Detection of Input conveyor sensor

P.C.B. on stop sensor was not detected after movement completion

Please check whether P.C.B. is detected correctly.

Checkwhetherthesensordoesn’thave

Error.

425109 Detection of Input conveyor sensor

P.C.B. on Input conveyor was detected

Remove P.C.B. from Conveyor.

42510a Detection of Input conveyor sensor

P.C.B. on Input conveyor was not detected

Please check whether P.C.B. is detected correctly. Check whether the sensor

doesn’thaveError.

42510b Detection of Input conveyor sensor

2 P.C.B. pieces on conveyor exist.

Remove it if unnecessary P.C.B. exists, when checking P.C.B. on Conveyor.

42510c

Detection of Input conveyor sensor

P.C.B. on sensor was detected in the state of not placing P.C.B.

There is a possibility whether P.C.B. is inserted or P.C.B. arrived before detecting

signals.

42510d Detection of Input conveyor sensor

Disengaged P.C.B. of Input conveyor

Possible to driver continuously.

PleaseconrmthestateofP

.C.B.ifitisnotremovedpurposely

42510e Detection of Input conveyor sensor

P.C.B. was not detected when placement was completed

P.C.B. from Input Machine is not received and sent.

PleaseconrmwhetherP.C.B.on

Inputconveyoriscaught.

42510f Detection of Input conveyor sensor

P.C.B. was detected from Input conveyor sensor

P.C.B. is inserted though the mode that could not be inserted.

Please remove the inserted P.C.B..
