4OM-1603 4-1 1. Description of Recognition Error ID (Example) : Chap.4 1012-005 1. Description of Recognition Error ID (Example) [1] [2] Recognition Error ID Description of Recognition Error 050**001 Component was not fo…
4OM-1603
1012-005 4-B
4OM-1603
4-1
1. Description of Recognition Error ID (Example) : Chap.4
1012-005
1. Description of Recognition Error ID (Example)
[1]
[2]
Recognition Error ID Description of Recognition Error
050**001 Component was not found.
051**001 Component was not detected.
T4D1
[1] Recognition Error ID
The recognition error IDs (IDs displayed in the "ERROR" window) are
described in the numerical order.
[2] Description of Recognition Error
Described are the contents of a recognition error that will be displayed in the
"ERROR" window.
4OM-1603
4-2
2. Recognition Error IDs and Controlled Areas : Chap.4
2. Recognition Error IDs and Controlled Areas
Basic System of Recognition Error IDs
An error ID is expressed by 8 digits (hexadecimal) as follows.
Z A B CC DDD
Detailed Classification
Small Classification
Middle Classification
Large Classification : Classification based on individual
recognition functions
Classification Criteria : Distinction between Recognition
System and Ordinary Errors
ClassicationCriteria
ClassicationCriteria ClassicationofRecognitionFunctions
0 Ordinary Errors
1 Recognition System Errors
T4D2
LargeClassication
ClassicationCriteria ClassicationofRecognitionFunctions
0 Recognition Internal Errors
1 Recognition Communication Errors
2 Recognition Communication Errors
5 Component Recognition Errors
6 PEC Recognition Errors
7 Nozzle Recognition Errors
8 Character Recognition Errors
9 Bad Mark Detection Errors
a Recognition Teaching Errors (Reserved)
b
Component Library
Teaching Function Errors
c 2D Barcode Errors
d Support pin Detection Errors
f Vision System Start-up Errors
T4D3
