4OM-1603
3-89
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496512 Error of Shuttle conveyor width W1 in Output side
Out-of-Control in Conveyor Width W1
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496513 Error of Shuttle conveyor width W1 in Output side
Error in Motor Power voltage of Conveyor Width W1
Motor power voltage dropped. Check out the Power supply line(48V Line)
496514 Error of Shuttle conveyor width W1 in Output side
STP input in Conveyor Width W1 was detected
STP input is detected. The function to stop motor by Hard signal.
496515 Error of Shuttle conveyor width W1 in Output side
Over-current in Conveyor Width W1
Error in Motor output line. Check out the motor wiring,
496516 Error of Shuttle conveyor width W1 in Output side
Limit Sensor(+) was detected in Conveyor Width W1.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496517 Error of Shuttle conveyor width W1 in Output side
Limit Sensor(-) was detected in Conveyor Width W1.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496518 Error of Shuttle conveyor width W1 in Output side
Motor Disconnection of Conveyor Width W1 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496519 Error of Shuttle conveyor width W1 in Output side
Control Power Voltage of Conveyor Width W1 has error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49651a Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651b Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651c Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651d Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49651e Error of Shuttle conveyor width W1 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
1012-005
4OM-1603
3-90
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49651f Error of Shuttle conveyor width W1 in Output side
System Error in Conveyor Width W1.
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
496610 Error of Shuttle Conveyor width W2 in Output side
System setup of Conveyor Width W2 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
496611 Error of Shuttle Conveyor width W2 in Output side
Zeroing Error in Conveyor Width W2
LS, discontinuous zeroing movement, was detected. Check out the dirt, error of
sensor and error in Motor body etc.
496612 Error of Shuttle Conveyor width W2 in Output side
Out-of-Control in Conveyor Width W2
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496613 Error of Shuttle Conveyor width W2 in Output side
Error in Motor Power voltage of Conveyor Width W2
Motor power voltage dropped. Check out the Power supply line(48V Line)
496614 Error of Shuttle Conveyor width W2 in Output side
STP input in Conveyor Width W2 was detected
STP input is detected. The function to stop motor by Hard signal.
496615 Error of Shuttle Conveyor width W2 in Output side
Over-current in Conveyor Width W2
Error in Motor output line. Check out the motor wiring,
496616 Error of Shuttle Conveyor width W2 in Output side
Limit Sensor(+) was detected in Conveyor Width W2.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496617 Error of Shuttle Conveyor width W2 in Output side
Limit Sensor(-) was detected in Conveyor Width W2.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496618 Error of Shuttle Conveyor width W2 in Output side
Motor Disconnection of Conveyor Width W2 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496619 Error of Shuttle Conveyor width W2 in Output side
Control Power Voltage of Conveyor Width W2 has an error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49661a Error of Shuttle Conveyor width W2 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
1012-005
4OM-1603
3-91
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49661b Error of Shuttle Conveyor width W2 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49661c Error of Shuttle Conveyor width W2 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49661d Error of Shuttle Conveyor width W2 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49661e Error of Shuttle Conveyor width W2 in Output side
-----
Reserved Function of driver. Please make inquiries when error is detected.
49661f Error of Shuttle Conveyor width W2 in Output side
System Error in Conveyor Width W2.
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
496801 Transit communication Error
Communication error occurred in the transfer section.
1.
Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496802 Conveyor Width W1-axis communication Error
Communication error occurred in the W1-axis transfer driver.
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496803 Conveyor Width W2-axis communication Error
Communication error occurred in the W2-axis transfer driver.
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496901 Conveyor Width-axis Time-out
Time-out of Zeroing
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496902 Conveyor Width-axis Time-out
Time-out
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
496a01 Shuttle Conveyor Error (Input side)
The Cover of Shuttle Conveyor is open.
Please close the cover, and then operate. There is a possibility of Loose
Connection or Defect if the cover is close.
