4OM-1603 3-30 3. Error IDs and Remedial Procedures : Chap.3 1012-005 Error ID Error Name, Description, Cause, and Remedy 42131d Error in the movement of output conveyor ----- Reserved Function of driver . Please make inq…
4OM-1603
3-29
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
421310 Error in the movement of output conveyor
System setup of output conveyor is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
421311 Error in the movement of output conveyor
Zeroing Error of output conveyor
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
421312 Error in the movement of output conveyor
Out-of-Control of output conveyor
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
421313 Error in the movement of output conveyor
Error in motor power voltage of output conveyor
Motor power voltage dropped. Check out the Power supply line(48V Line)
421314 Error in the movement of output conveyor
STP input on output conveyor was detected
STP input is detected. The function to stop motor by Hard signal.
421315 Error in the movement of output conveyor
Over-current on output conveyor
Abnormal
currentinmotoroutputline
wasdetected.Conrmthemotorwiring,
supplying power.
421316 Error in the movement of output conveyor
Limit sensor(+) of output conveyor was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
421317 Error in the movement of output conveyor
Limit sensor(-) of output conveyor was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
421318 Error in the movement of output conveyor
Disconnecting Motor of output conveyor was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
421319 Error in the movement of output conveyor
Error in control power voltage of output conveyor
Control power for driver dropped. Check out the Power supply line.(24V Line)
42131a Error in the movement of output conveyor
-----
Reserved Function of driver. Please make inquiries when error is detected.
42131b Error in the movement of output conveyor
-----
Reserved Function of driver. Please make inquiries when error is detected.
42131c Error in the movement of output conveyor
-----
Reserved Function of driver. Please make inquiries when error is detected.
4OM-1603
3-30
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
42131d Error in the movement of output conveyor
-----
Reserved Function of driver. Please make inquiries when error is detected.
42131e Error in the movement of output conveyor
-----
Reserved Function of driver. Please make inquiries when error is detected.
42131f Error in the movement of output conveyor
System Error on positioning conveyor
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
421401 A-lane Input conveyor
-----
-----
421501 A-lane positioning Conveyor
-----
-----
421601 A-lane output conveyor
-----
-----
421701 B-lane Input conveyor
-----
-----
421801 B-lane positioning conveyor
-----
-----
421901 B-lane output conveyor
-----
-----
422001 Simultaneous transfer timeout
Timeout during simultaneous transfer
Time-out of placement on Output Conveyor, Positioning Conveyor.
Please check P.C.B. position on conveyor.
422101 Input conveyor error
P.C.B. placement was not completed within predetermined time.
Time-out of P.C.B. placement from Input.
There is possibilities that P.C.B. is stopping on conveyor and it is not detected in
sensor. Please check Stagnated P.C.B..
422102 Input conveyor error
P.C.B. on input section was detected before placement is ready completely
The supplying entrance sensor detected P.C.B.(Carried out manual bypass, or
Placed between 2 pieces of Stagnated P.C.B. on conveyor)
422103 Input conveyor error
Placement is completed, but P.C.B. is not placed.
It stopped in the position where could not detect P.C.B. by P.C.B. slit, or P.C.B.
is
fallen.PleasecheckP.C.B.
ofsupplyingsection,andresetit.Conrmthe
adjustment of the width of Conveyor.(Set P.C.B. the position detected by sensor)
4OM-1603
3-31
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
422104 Input conveyor error
Stop sensor of Input conveyor was detected while P.C.B. was ready for placing.
Remove Stagnated P.C.B., Please set P.C.B. correct positioning. (manual moving)
422201 positioning conveyor Error
Time Over in placement of product position(L)
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422202 positioning conveyor Error
Time Over in the downward on Backup(L) axis
-----
422203 positioning conveyor Error
Conveyor did not stop
-----
422204 positioning conveyor Error
Upward timeout on Backup(L) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422301 positioning conveyor Error
Time Over in placement of product position(R)
Remove Stagnated P.C.B., Please set P.C.B. correct positioning. (manual moving)
422302 positioning conveyor Error
Time Over in the downward on Backup(R) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422303 positioning conveyor Error
Conveyor did not stop
-----
422304 positioning conveyor Error
Upward timeout on Backup(R) axis
Motor is not completed. Please check motor error or Pattern program set value
because there is a possibility that time-over value is inputted.
422401 Output Conveyor Error
P.C.B. output was not completed within predetermined time.
P.C.B. is stagnating in P.C.B. Output for Output Machine. Please set stagnated
P.C.B.
422402 Output Conveyor Error
The output was completed, but P.C.B. is still placed on output conveyor .
P.C.B is stagnated although the movement in the position of transfer start is done.
Please
conrmthestagnatedP.C.B.
andConveyortransitsection.
422403 Output Conveyor Error
No P.C.B. on output conveyor
P.C.B. was not detected when output started. There is a possibility whether not
detected by P.C.B. Slit or it is fallen. Please set correctly after checking P.C.B..
Conrmtheadjustmentofconveyorwidth.
422404
Output Conveyor Error
Stop sensor of output conveyor was detected while P.C.B. was ready for placing
Remove Stagnated P.C.B.
