4OM-1603
3-71
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.6 Recognition Communication
Error ID Error Name, Description, Cause, and Remedy
450101 Recog. Comm. Error
Recognition Error Code.
-----
450102 Recog. Comm. Error
Time-Out Error
-----
450103 Recog. Comm. Error
GUI starting failure.
-----
450104 Recog. Comm. Error
There is the difference with settings for PEC Recognition Camera1.
-----
450105 Recog. Comm. Error
There is the difference with settings for PEC Recognition Camera2.
-----
450111 Recog. Comm. Error
Time-out of Light Change
-----
450112 Recog. Comm. Error
Time-out of Screen Capture
-----
450113 Recog. Comm. Error
Time-out of Recog
-----
450121 Recog. Comm. Error
Time-out of Recog
-----
450122 Recog. Comm. Error
Time-out of Light Change for 2D bar code
-----
450123 Recog. Comm. Error
Time-out of Screen Capture for 2D bar code
-----
T4C8
4OM-1603
3-72
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.7 PEC Recognition
Error ID Error Name, Description, Cause, and Remedy
460101 P.E.C. Inspection
P.E.C. Mark #1 (Global)
-----
460102 P.E.C. Inspection
P.E.C. Mark #2 (Global)
-----
460103 P.E.C. Inspection
P.E.C. Mark #3 (Global)
-----
460104 P.E.C. Inspection
P.E.C. Mark #1 (Image)
-----
460105 P.E.C. Inspection
P.E.C. Mark #2 (Image)
-----
460106 P.E.C. Inspection
P.E.C. Mark #3 (Image)
-----
460107 P.E.C. Inspection
P.E.C. Mark #1 (Local)
-----
460108 P.E.C. Inspection
P.E.C. Mark #2 (Local)
-----
460109 P.E.C. Inspection
P.E.C. Mark #3 (Local)
-----
46010a P.E.C. Inspection
Land P.E.C. Mark #1
-----
46010b P.E.C. Inspection
Land P.E.C. Mark #2
-----
46010c P.E.C. Inspection
Land P.E.C. Mark #3
-----
46010d P.E.C. Inspection
Failed in P.E.C. Recognition
Please perform to the following
1.
Repeat P.C.B. positioning
2. ConrmwhethertheMark
positionofP.C.B.Recognitioniscorrect.
4OM-1603
3-73
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
46010e P.E.C. Inspection
Failed in Land recog
Please perform methods to the following.
1. Check Mark on the PCB
2. Revise PCB positioning
460201 2D bar code Error
Failed in reading 2D bar code
Please perform to the following
1. The condition of PCB Positioning
2. Specify the position of 2D bar code
3. Detect the dirty of 2D bar code
