4OM-1603

3-58

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

438506 Multi-Tray (Rear)

Communication Status Error(Connection O)

PleaseconrmAE-LINKwiringandPower

wiring.

438507 Multi-Tray (Rear)

Communication Status Error(Driver Alarm)

PleaseconrmAE-LINKwiringandPower

wiring.

438508 Multi-Tray (Rear)

Communication Status Error(SV-net stopping)

PleaseconrmAE-LINKwiringandPower

wiring.

438509 Multi-Tray (Rear)

Communication Status Error(Out of Connection number)

PleaseconrmAE-LINKwiringandPower

wiring.

43850A Multi-Tray (Rear)

Communication Status Error(SV-VET Error)

PleaseconrmAE-LINKwiringandPower

wiring.

43850B Multi-Tray (Rear)

Failed to read the number of Axes

PleaseconrmAE-LINKwiringandPower

wiring.

43850C Multi-Tray (Rear)

Driver-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

43850D Multi-Tray (Rear)

Elevator1-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

43850E Multi-Tray (Rear)

Elevator2-aixs in not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

438510 Multi-Tray (Rear)

Motor Breaker Trip Error

-----

438511 Multi-Tray (Rear)

Elevator Unit is not connected.

Please connect Elevator unit in Unit exchange menu.

438512 Multi-Tray (Rear)

All connectors of Elevator Unit are not connected.

Pleaseconrmtheconnectiontoall

connectorofElevatorUnit

438513 Multi-Tray (Rear)

Failed to start-up Communication of SV-NET.

PleaseconrmAE-LINKwiringandPower

wiring.

438514 Multi-Tray (Rear)

Failed to turn on Multi-tray.(Time-out)

-----

438515 Multi-Tray (Rear)

(AtnishingAutoRun)Multi-trayoperation

isnotcompletedwithinaspecied

time.

Please push Emergency Stop button.

4OM-1603

3-59

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

438601 Multi-Tray (Servo Error) (Rear)

Error of Power Driver, Over-current

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

438602 Multi-Tray (Servo Error) (Rear)

Overload Alarm

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

438603 Multi-Tray (Servo Error) (Rear)

Speed Alarm

You need to re-adjust Motor Gain.

438604 Multi-Tray (Servo Error) (Rear)

Multi-rotation Error

PleaseconrmMotorwiring,ExchangeMotor

andDriver.

438605 Multi-Tray (Servo Error) (Rear)

The value of Deviation Counter was over the set value

PleaseconrmthewiringofOrigin

Sensor,orexchangeDriver.

438606 Multi-Tray (Servo Error) (Rear)

Power Drive detected temperature error.

Ambient Temperature is too high. Or, exchange driver.

438607 Multi-Tray (Servo Error) (Rear)

Sensor Error

PleaseconrmMotorEncoderwiring.Or

,exchangemotor

438608 Multi-Tray (Servo Error) (Rear)

High Drive voltage

Insufcientpowercapacity.Pleaseexchange

driver.

438609 Multi-Tray (Servo Error) (Rear)

Low drive voltage

PleaseconrmtheoperatingPowerwiring

whichisinsertedtodriver.

43860A Multi-Tray (Servo Error) (Rear)

Reading Error on permanent memory

Please exchange driver.

43860B Multi-Tray (Servo Error) (Rear)

Reading Error on permanent memory

Please exchange driver.

43860C Multi-Tray (Servo Error) (Rear)

CPU Error

Please exchange driver.

43860D Multi-Tray (Servo Error) (Rear)

Parameter Error

Please

conrmthechangedparameter.

43860E Multi-T

ray (Servo Error) (Rear)

Alarm code readout failed

-----

438701 Elevator Recede position operating error (Rear)

Elevator pre-check error

-----

4OM-1603

3-60

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

438702 Elevator Recede position operating error (Rear)

Error of calculating Elevator movement position

-----

438703 Elevator Recede position operating error (Rear)

Elevator Start Time-out

-----

438704 Elevator Recede position operating error (Rear)

Elevator movement error

-----

438705 Elevator Recede position operating error (Rear)

Elevator movement Time-out

-----

438801 Elevator comp. position operating error (Rear)

Elevator pre-check error

-----

438802 Elevator comp. position operating error (Rear)

Error of calculating Elevator movement position

-----

438803 Elevator comp. position operating error (Rear)

Elevator Start Time-out

-----

438804 Elevator comp. position operating error (Rear)

Elevator movement error

-----

438805 Elevator comp. position operating error (Rear)

Elevator movement Time-out

-----
