4OM-1603
3-63
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
441404 Tray Pallet Draw out Error (Front)
Traverse operating error
-----
441405 Tray Pallet Draw out Error (Front)
Traverse operating error
-----
441406 Tray Pallet Draw out Error (Front)
No palette when drawing out begins. (B0511)
-----
441407 Tray Pallet Draw out Error (Front)
Cannot detect the pallet to pull out(B15505, B15506)
Pleaseconrmwhetherthepalletin
themagazineissetproperly.Ifso,adjustthe
sensor, please.
441501 Move to Tray Elevator supply/exchange position error (Front)
Elevator pre-check error
-----
441502 Move to Tray Elevator supply/exchange position error (Front)
Elevator movement position error
-----
441504 Move to Tray Elevator supply/exchange position error (Front)
Elevator operating error
-----
441602 Tray Feeder Zeroing Error (Front)
Tray feeder zeroing Servo ON error
-----
441603 Tray Feeder Zeroing Error (Front)
Traverse pallet search error
-----
441604 Tray Feeder Zeroing Error (Front)
Elevator zeroing error
-----
441605 Tray Feeder Zeroing Error (Front)
Elevator zeroing error
-----
441606 Tray Feeder Zeroing Error (Front)
The palette was detected though there was no draw out history.
-----
441607 Tray Feeder Zeroing Error (Front)
Elevator return steps movement error
-----
441608 Tray Feeder Zeroing Error (Front)
Traverse pallet store error
-----
441609 Tray Feeder Zeroing Error (Front)
Elevator zeroing pre-check error
-----
4OM-1603
3-64
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
44160a Tray Feeder Zeroing Error (Front)
Pallet chuck close error
-----
44160b Tray Feeder Zeroing Error (Front)
Rack shutter CLOSE error
-----
44160c Tray Feeder Zeroing Error (Front)
Elevator zeroing error
-----
44160d Tray Feeder Zeroing Error (Front)
EV1 step logs and step movement error
-----
44160e Tray Feeder Zeroing Error (Front)
Ev2 step logs and step movement error
-----
44160f Tray Feeder Zeroing Error (Front)
Traverse zeroing error
-----
441610 Tray Feeder Zeroing Error (Front)
Traverse zeroing pre-check error
-----
441611 Tray Feeder Zeroing Error (Front)
Pallet chuck CLOSE error
-----
441613 Tray Feeder Zeroing Error (Front)
Pallet chuck OPEN error
-----
441614 Tray Feeder Zeroing Error (Front)
Traverse recede operation error
-----
441615 Tray Feeder Zeroing Error (Front)
The palette was not detected though there was a draw out history.
-----
441616 Tray Feeder Zeroing Error (Front)
Rack shutter OPEN error(Upper Magazine)
-----
441617 Tray Feeder Zeroing Error (Front)
Rack shutter OPEN error(Lower Magazine)
-----
441618 Tray Feeder Zeroing Error (Front)
The other pallet was detected from pallet store position during pulling.
-----
441619 Tray Feeder Zeroing Error (Front)
Traverse zeroing error
-----
4OM-1603
3-65
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
44161a Tray Feeder Zeroing Error (Front)
Pallet chuck CLOSE error
-----
44161b Tray Feeder Zeroing Error (Front)
Rack shutter CLOSE error
-----
44161c Tray Feeder Zeroing Error (Front)
Magazine(Down) Error in shifting Pallet existence detection position.
-----
44161d Tray Feeder Zeroing Error (Front)
Magazine(Up) Error in shifting Pallet existence detection position.
-----
441801 Tray Feeder in advance check error
Tray power supply not turning on(power supply cut off from main machine)
-----
441802 Tray Feeder in advance check error
-----
Please close the body safety cover, and then press "READY" button, lock the
cover.
441803 Tray Feeder in advance check error
Tray maintenance cover OPEN
-----
441804 Tray Feeder in advance check error
Traverse axis main circuit was cut off
-----
441805 Tray Feeder in advance check error
Safety circuit cut off
-----
441806 Tray Feeder in advance check error
Elevator axis main circuit cut off
-----
441807 Tray Feeder in advance check error
Tray Safety Cover(Upper) is open.
Please close Tray safety Cover(Upper), and then press "READY" button, lock the
cover.
441808 Tray Feeder in advance check error
Tray Safety Cover(Center) is open.
Please close Tray safety Cover(Center), and then press "READY" button, lock the
cover.
441809 Tray Feeder in advance check error
Tray Safety Cover(Lower) is open.
Please close Tray safety Cover(Lower), and then press "READY" button, lock the
cover.
44180a Tray Feeder in advance check error
Feeder base is "Ready On"
Please
conrmFeederCartsetcorrectly
,andpressFeederBase"READY"
button.
