4OM-1603
1-13
2. Maintenance Check List : Chap.1
2.4 Quarterly Maintenance
Grease Symbols
DE1
: DAPHNE EPONEX GREASE No. 1
NM1
: MOLYNOC GREASE AP1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.1 Air Source
Filter
Cleaning
-----
3.2.2 Vacuum System
Driving Section
Filter
Cleaning
-----
3.2.4 Feeder Base
Worm Gear
Lubrication
NM1
3.2.6 Feeder Cart
Section (Cutter)
Linear Guide
Lubrication
DE1
Needle Bearing
Lubrication
DE1
3.2.7 Head Section
High Speed Head
Nozzle U/D Ball Screw
(NL Axis)
Cleaning,
Lubrication
DE1
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
DE1
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
DE1
Center Spline
Lubrication
DE1
Carn Follower
Cleaning,
Lubrication
DE1
Nozzle Change Carn
Face (Upper Side)
Cleaning,
Lubrication
DE1
Vacuum Filter
Replacement
-----
Vacuum Nozzle
Inspection
-----
3.2.7 Head Section
Multi-Functional
Head
Ball Screw (3 locations)
Lubrication
DE1
Linear Guide
(3 locations)
Lubrication
DE1
Pan
(3 locations)
Cleaning
----- Oiled Rag
Vacuum Filter
Change
----- Filter Attachment /
Detachment Jig
Vacuum Nozzle
Inspection
-----
3.2.8 X/Y Beam
Section
* X-Axis Linear Guide
Cleaning,
Lubrication
DE1
* Y-Axis Linear Guide
Cleaning,
Lubrication
DE1
X-Axis Linear Scale
Cleaning
-----
Y-Axis Linear Scale
Cleaning
-----
3.2.9 PCB Positioning
Section
* Ball Screw
Cleaning,
Lubrication
DE1
3.2.10 Conveyor
Section
* Linear Guide
Cleaning,
Lubrication
DE1
T4A12
1012-005
4OM-1603
1-14
2. Maintenance Check List : Chap.1
1012-005
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.11 Nozzle Stocker
Section
Nozzle Stocker
for High Speed
Nozzle
Nozzle Stocker Sliding
Area
Cleaning,
Lubrication
DE1 Oiled Rag
Shutter Flange Pin
Sliding Section
Cleaning,
Lubrication
NM1
Nozzle Stocker
for Multi-
Functional
Nozzle
Nozzle Stocker Sliding
Area
Cleaning,
Lubrication
DE1 Oiled Rag
Shutter Flange Pin
Sliding Section
Cleaning,
Lubrication
NM1
3.2.12 Control Box
Section
Filter
Cleaning
-----
3.2.13 Fans
Ventilating Fan
Cleaning
-----
Air-Intake Fan
Cleaning
-----
T4A13
2.5 Half-Yearly Maintenance
Grease Symbols
DE1
: DAPHNE EPONEX GREASE No. 1
IEL/V
: BARRIERTA IEL/V
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.8 X/Y Beam
Section
X-Axis Cable Side Face
Cleaning,
Lubrication
IEL/V Oiled Rag, Brush
X-Axis Cable Fixing
Places
Inspection
----- -----
X-Axis Liner Scale
Cleaning
----- Rag
Y-Axis Cable Side Face
Cleaning,
Lubrication
IEL/V Oiled Rag, Brush
Y-Axis Cable Fixing
Places
Inspection
----- -----
Y-Axis Liner Scale
Cleaning
----- Rag
3.2.9 PCB Positioning
Section
Ball Screw Splines
Cleaning,
Lubrication
DE1 Oiled Rag,
Hand Grease Gun,
SPK-3C
T4A14
2.6 Yearly Maintenance
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
3.2.6 Feeder Cart
Section (Cutter)
Fluorine Sheet
Change
----- Screwdriver, Wrench
Urethane Clamp Assy
Change
----- Screwdriver, Wrench
Flat Ring
Change
----- Screwdriver, Wrench, Torque
driver
3.2.7 Head Section
High Speed Head
Nozzle Shaft
Inspection
Cleaning
----- Flow Meter
Vacuum System
T4A15
4OM-1603
1-15
3. Maintenance Spots : Chap.1
3. Maintenance Spots
3.1 Whole View
Notice
Any operations with a cover(s) being removed are included.
After the maintenance work, be sure to attach the cover.
Feeder Cart Section
Air Source
Vacuum System
Front View of Machine
F4A6
Reference
(a) Refer to "3.2" and the subsequent items for the detailed information on the
spots of each section to be maintained and how to maintain them.
(b) As for the options, refer to each instruction manual of the specially
specied devices for the maintenance.
