4OM-1603
3-116
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.11 Handling Error
Error ID Error Name, Description, Cause, and Remedy
500101 Comp. Missing (Sensor)
Comp. Missing (Sensor)
There is a possibility that the picked comps. have fallen on the feeder and please
conrmit.
500301 Comp. Missing (Recog)
Comp. Missing (Recog)
There is a possibility that the picked comps. have fallen on the feeder and please
conrmit.
500401 Comp. Recog Error
Comp. Recog Error
-----
500501 Shortage of Component
Shortage of Component
-----
500502 Feeder Reload Stop
Feeder Reload Stop (Splicing)
-----
500c01
Comp. Vertical(Sensor)
Comp. Vertical(Sensor)
-----
500f01 Comp.
Thickness(Sensor)
Comp. Thickness(Sensor)
-----
501001
-----
T4C13
4OM-1603
3-117
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.12 Automatic Operation Error
Error ID Error Name, Description, Cause, and Remedy
510a01 Feeder Pocket recog Error
Abnormality occurred in process of recognizing Feeder Pocket.
-----
510b01 Auto Run Error
Master bad mark detection is abnormal.
-----
510b02 Auto Run Error
Bad mark detection is abnormal.
-----
510e01 Nozzle air blow Error(Rear)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510e02 Nozzle air blow Error(Rear)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510e03 Nozzle air blow Error(Rear)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f01 Nozzle air blow Error(Front)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f02 Nozzle air blow Error(Front)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
510f03 Nozzle air blow Error(Front)
Because abnormality had occurred while processing the nozzle air blow,
processing was interrupted.
-----
511001 Head Preparation Error(Rear)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511002 Head Preparation Error(Rear)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511003 Head Preparation Error(Rear)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
4OM-1603
3-118
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
511004 Head Preparation Error(Rear)
There is a possibility that Nozzle is falling while processing the preparation.
PleaseconrmtheplacedNozzleon
Head.
-----
511101 Head Preparation Error(Front)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511102 Head Preparation Error(Front)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511103 Head Preparation Error(Front)
Because abnormality had occurred while processing the preparation, processing
was interrupted.
-----
511104 Head Preparation Error(Front)
There is a possibility that Nozzle is falling while processing the preparation.
Please
conrmtheplacedNozzleon
Head.
-----
511201 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(L) are detected
simultaneously.
-----
511202 Transfer Section's Preparation Error
Upward movement on PCB Stopper(L) is abnormal.
-----
511203 Transfer Section's Preparation Error
Downward movement on PCB Stopper(L) is abnormal.
-----
511204 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(R) are detected
simultaneously.
-----
511205 Transfer Section's Preparation Error
Upward movement on PCB Stopper(R) is abnormal.
-----
511206 Transfer Section's Preparation Error
Downward movement on PCB Stopper(R) is abnormal.
-----
511207 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AL) are detected
simultaneously.
-----
511208 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AL) is abnormal.
-----
1012-005
