4OM-1603
3-144
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604417 Teaching Height of Stocker Master
Thereisnomeasureddataof
Noz1.ItisnecessarytomeasureNoz1rst.
-----
604418 Teaching Height of Stocker Master
CannotmeasureitforXY-coord
isnotdened.
-----
604419 Teaching Height of Stocker Master
Error in Flowing Quantity
-----
604501 Teaching Pickup-Height
Error is detected before starting Detection on Linear Measure Sensor. (There is a
possibility that Linear measure sensor is broken, or Odd Noz is placed.)
-----
604502 Teaching Pickup-Height
Time-out of [OFF] signal of Linear measure sensor
-----
604503 Teaching Pickup-Height
Error in DD-axis
-----
604504 Teaching Pickup-Height
Error in NS-axis
-----
604505 Teaching Pickup-Height
Error in DD/NS-axis
-----
604506 Teaching Pickup-Height
Time-out of DD/NS-axis
-----
604507 Teaching Pickup-Height
Error in calculating drive wave of HL-axis
-----
604508 Teaching Pickup-Height
Error in calculating drive wave of NL-axis
-----
604509 Teaching Pickup-Height
Time-out of starting HL/NL-axis movement
-----
60450a Teaching Pickup-Height
Time-out of starting HL-axis movement
-----
60450b Teaching Pickup-Height
Time-out of starting NL-axis movement
-----
60450c Teaching Pickup-Height
T
ime-outofnishingHL/NL-axismovement
-----
1012-005
4OM-1603
3-145
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
60450d Teaching Pickup-Height
Failed in measuring real time of linear measure sensor.
-----
60450e Teaching Pickup-Height
Error in measuring Linear measure sensor
-----
60450f Teaching Pickup-Height
Flange of Nozzle is not detected within the predetermine range.(Under 0.2mm)
-----
604510 Teaching Pickup-Height
Flange of Nozzle is not detected within the predetermine range.(Over 2.5mm)
-----
604511 Teaching Pickup-Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604512 Teaching Pickup-Height
Program Error
-----
604513 Teaching Pickup-Height
Offset is 1mm less than the set value.
-----
604514 Teaching Pickup-Height
Offset is 1mm more than the set value.
-----
604515 Teaching Pickup-Height
The value of Flowmeter is higher than 5.0V.
-----
604516 Teaching Pickup-Height
The value of Flowmeter is lower than 4.7V.
-----
604517 Teaching Pickup-Height
There
isnomeasureddataof
Noz1.ItisnecessarytomeasureNoz1rst.
-----
604518 Teaching Pickup-Height
CannotmeasureitforXY-coord
isnotdened.
-----
604519 Teaching Pickup-Height
Error in Flowing Quantity
-----
604601 Teaching Height of Glass Jig
Error is detected before starting Detection on Linear Measure Sensor.(There is a
possibility that Linear measure sensor is broken, or Odd Noz is placed.)
-----
604602 Teaching Height of Glass Jig
Time-out of [OFF] signal of Linear measure sensor
-----
1012-005
4OM-1603
3-146
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604603 Teaching Height of Glass Jig
Error in DD-axis
-----
604604 Teaching Height of Glass Jig
Error in NS-axis
-----
604605 Teaching Height of Glass Jig
Error in DD/NS-axis
-----
604606 Teaching Height of Glass Jig
Time-out of DD/NS-axis
-----
604607 Teaching Height of Glass Jig
Error in calculating drive wave of HL-axis
-----
604608 Teaching Height of Glass Jig
Error in calculating drive wave of NL-axis
-----
604609 Teaching Height of Glass Jig
Time-out of starting HL/NL-axis movement
-----
60460a Teaching Height of Glass Jig
Time-out of starting HL-axis movement
-----
60460b Teaching Height of Glass Jig
Time-out of starting NL-axis movement
-----
60460c Teaching Height of Glass Jig
T
ime-outofnishingHL/NL-axismovement
-----
60460d
Teaching Height of Glass Jig
Failed in measuring real time of linear measure sensor.
-----
60460e Teaching Height of Glass Jig
Error in measuring Linear measure sensor
-----
60460f Teaching Height of Glass Jig
Flange of Nozzle is not detected within the predetermine range.(Under 0.2mm)
-----
604610 Teaching Height of Glass Jig
Flange of Nozzle is not detected within the predetermine range.(Over 2.5mm)
-----
604611 Teaching Height of Glass Jig
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
1012-005
