4OM-1603 2-27 3. Machine Information : Chap.2 Machine Information Code Display Area A (The outline of the Machine Information) Display Area B (The details of the Machine Information) 809e02 Automatic T eaching Pleaseski…
4OM-1603
2-26
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
802603 Linear measure sensor
To reset DD origin position of Head(Rear) is failed.
-----
802604 Linear measure sensor
To reset DD origin position of Head(Front) is failed.
-----
803028 FAN Stop alarm
Fan rotation error of Control Box. Clean up Fan.
-----
803101 Feeder Feeding Pitch Correction
Auto Correction is executed for Feeder Feeding Pitch is out of position.
-----
809201 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
809301 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
809c01 Motor system error
Communication not establish with Servo Amp (XY Beam).
Check following
1.
Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809c02 Motor system error
Servo Amp parameter error.
1. There is a possibility that Motor Communication Line is
abnormal.
2. Parameter settings Error(0x21E).
809c03 Motor system error
Communication not establish with Servo Amp (Head).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3.
Communication cable.
809d01 Recycleconveyorlled
up
Recycle conveyor became Full. (Rear)
-----
809d02 Recycleconveyorlled
up
Recycle conveyor became Full. (Front)
-----
809e01 Automatic Teaching
Please
skipitbecauseAutomaticmodicationT
eachingisimpossibleinNozzle
position of Rear Head.
-----
1012-005
4OM-1603
2-27
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
809e02 Automatic Teaching
PleaseskipitbecauseAutomaticmodicationT
eachingisimpossibleinNozzle
position of Rear Head.
-----
809f01 Automatic Teaching
There is no magazine. Magazine 1 (Lower).
-----
809f02 Automatic Teaching
Rack shutter of operator side is open. Magazine 1 (Lower)
-----
809f03 Automatic Teaching
Rack shutter of traverse side is open. Magazine 1 (Lower)
-----
809f04 Automatic Teaching
The Magazine is not set correctly. Magazine 1 (Lower)
Check lock lever of magazine.
-----
809f05 Automatic Teaching
There is no magazine. Magazine 2 (Upper).
-----
809f06 Automatic Teaching
Rack shutter of operator side is open. Magazine 2 (Upper)
-----
809f07 Automatic Teaching
Rack shutter of traverse side is open. Magazine 2 (Upper)
-----
809f08 Automatic Teaching
The Magazine is not set correctly. Magazine 2 (Upper)
Check lock lever of magazine.
-----
809f09 Automatic Teaching
Motor Error of Magazine(Lower) is detected.
-----
809f0a Automatic Teaching
Motor Error of Magazine(Upper) is detected.
-----
80a001 Recognition Error
Failed in the recognition of the part. Please retry pickup of the part.
-----
80a002 Recognition Error
Nozzle position teaching failure.
Check nozzle condition.
-----
1012-005
4OM-1603
2-28
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
80a101 Reading the Linear measure sensor Version
The operation for turning on is invalid.
Please do operation again after turning on completely.
-----
80b001 Automatic Teaching Error
Failed in the recognition. Carr it out again on the next time.
-----
80c001 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Rear) Magazine1(Lower).
PleaseconrmthewiringofMachine
-----
80c002
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Rear) Magazine1(Upper).
PleaseconrmthewiringofMachine
-----
80c003
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Front) Magazine2(Lower).
PleaseconrmthewiringofMachine
-----
80c004
Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Front) Magazine2(Upper).
PleaseconrmthewiringofMachine
-----
80c101
Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Rear) Magazine1(Lower)
-----
80c102 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Rear) Magazine2(Upper)
-----
80c103 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Front) Magazine1(Lower)
-----
80c104 Multi-layered Tray ACV miss-placement error(Step)
Error of miss-placement : Tray(Front) Magazine2(Upper)
-----
80c201 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Rear) Magazine1(Lower) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
80c202 Multi-layered Tray ACV miss-placement error(Magazine)
Tray(Rear) Magazine2(Upper) Cannot use it in AUTO OPN MODE (PLACEMENT)
because of miss-placement.
-----
