4OM-1603
2-14
2. Management Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030432 Operation Requirement
The connector of the feeder base (rear) is not connected to the main body, so
please connect it. [B0916]
030433 Operation Requirement
The connector of the feeder base (front) is not connected to the main body, so
please connect it. [B0916]
030440 Operation Requirement
The Safety cover is open. Please close it.
030441 Operation Requirement
It is impossible to do Pass Operation without Cart because func of Traceability is
valid. Please restart after setting Option invalid.
030442 Operation Requirement
It cannot run because a simple Cover locked. First, set Stage ready OFF, then set
Stage ready ON.
030501 Misidenticationatypeofmulti-tray
The
connectedTrayunit(Rear)doesn'tmatchsetupofDevice.Pleaseconrma
type of tray unit, set it on unit exchange screen later.
030502 Misidenticationatypeofmulti-tray
The
connectedTrayunit(Front)doesn'tmatchsetupofDevice.Pleaseconrma
type of tray unit, set it on Unit Exchange Screen later.
030601 ConrmationofthepositionofNoz
Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Rear) on Unit exchange Screen.
030602 ConrmationofthepositionofNoz
Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Front) on Unit exchange Screen.
030603 ConrmationofthepositionofNoz
Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrmthelocationofNozstockerofDevice(Rear).
030604 ConrmationofthepositionofNoz
Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrmthelocationofNozstockerofDevice(Front).
030701 Conrmationof2DBarcodeData
MarkNo.ofOperatingParameter/2DBarCodedataisspeciedasAllSkip(0).
Please specify proper Mark No.
030801 Detect nozzle coming off multi-functional stocker
Machine(Rear) Detected that nozzle has come off the multi-functional stocker of
the 1st line.
030802 Detect nozzle coming off multi-functional stocker
Machine(Rear) Detected that nozzle has come off the multi-functional stocker of
the 4th line.
030803 Detect nozzle coming off multi-functional stocker
Machine(Front) Detected that nozzle has come off the multi-functional stocker of
the 1st line.
1012-005
4OM-1603
2-15
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030804 Detect nozzle coming off multi-functional stocker
Machine(Front) Detected that nozzle has come off the multi-functional stocker of
the 4th line.
050201 ConrmationofP.C.B.existence
Remove P.C.B. from Conveyor
050202 Conrmationof
P.C.B.existence
P.C.B. is detected from Input position because Finish mode is set [Output].
Please P.C.B. from conveyor.
050203 Conrmation
ofP.C.B.existence
P.C.B. is detected from Output position because Finish mode is set [Input].
Please P.C.B. from conveyor.
050204 Conrmation
ofP.C.B.existence
P.C.B. was detected from Inlet sensor of input conveyor.
Please remove P.C.B.
050205 Conrmation
ofP.C.B.existence
The operation mode of Lane A is set [STOP].
Please remove P
.C.B. when not transferred.
050206 ConrmationofP.C.B.existence
The operation mode of Lane B is set [STOP].
Please remove P.C.B. when not transferred.
050207 Conrmation
ofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the input conveyor. Please
remove PCB from Deceleration Sensor, or move it to Stop sensor, or delete the
PCB memory information.
050208 Conrmation
ofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the input conveyor in Lane
A. Please remove PCB from Deceleration Sensor, or move it to Stop sensor, or
delete the PCB memory information.
050209 Conrmation
ofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the output conveyor in
Lane B. Please remove PCB from Deceleration Sensor, or move it to Stop sensor,
or delete the PCB memory information.
05020a Conrmation
ofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
input side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
05020b Conrmation
ofP.C.B.existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
output side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
050301 Conrmation
ofFirmwareversion
Firmware of transfer driver is not the latest version.
Please update it with the latest version.
050401 Manual transfer
P.C.B. (X>260mm) which is set by PP data is unable to take Input Position.
4OM-1603
2-16
2. Management Information : Chap.2
1012-005
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050402 Manual transfer
Please operate after removing P.C.B. from output conveyor. There is a possibility
of pushing and rising with Stopper.
050403 Manual transfer
It is impossible to take from Sensor Detection of Input Position.
Please put P.C.B. on Input Conveyor, or move it to Output position in Recovery
Menu.
050404 Manual transfer
PCB (X>260mm) which is set by PP data is unable to be taken in Input Conveyor.
050405 Manual transfer
There is PCB on Deceleration Sensor of Input Conveyor. There is a possibility that
PCB is inserted.
050406 Manual transfer
There is PCB on Deceleration Sensor of Shuttle Conveyor in Output side. There
is a possibility that PCB is inserted.
050407 Manual transfer
Lane A is not able to be set in Current Program. Please change Current Program
or change to Lane B.
050408 Manual transfer
Lane B is not able to be set in Current Program. Please change Current Program
or change to Lane A.
050409 Manual transfer
PCB Y size and Conveyor Width in Current Program are not equal. Please change
Current Program.
050501 Convert Width Setup
Please set conveyor width 49.5mm 461.5mm.
The total of P.C.B. size/offset/clearance is over movable range.
050502 Convert Width Setup
Please set conveyor width 49.5mm 382.5mm.
The total of P.C.B. size/offset/clearance is over movable range.
050503 Convert Width Setup
Movable Range for the destination of W1 is set.
Please check P.C.B. size/offset/clearance of Lane A.
050504 Convert Width Setup
Movable Range for the destination of W1 is set.
Please check P.C.B. size/offset/clearance of Lane A.
050505 Convert Width Setup
Movable Range for the destination of W2 is set.
Please check P.C.B. size/offset/clearance of Lane A
050506 Convert Width Setup
Movable Range for the destination of W2 is set.
Please check P.C.B. size/offset/clearance of Lane A.
050507 Convert Width Setup
Movable Range for the destination of W3 is set.
Please check P.C.B. size/offset/clearance of Lane B.
