4OM-1603
3-137
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
602905 -----
-----
-----
602906 -----
-----
-----
602907 -----
-----
-----
602908 -----
-----
-----
603001 XY Origin teach
Failed to recognize Origin Correction Mark
Modify the teaching position and execute teaching again.
604001 Automatic Teaching on producing operation.
Failed to recognize a nozzle in Head rotation center offset teaching.
-----
604002 Automatic Teaching on producing operation.
Error in recognition command response in Head rotation center offset teaching.
-----
604003 Automatic Teaching on producing operation.
Could not recognize the Standard Mark.
-----
604101 Teaching Placement-Height
Error is detected before starting Detection on the Linear Sensor.(There is a
possibility that the Linear measure Sensor is broken , or Odd Noz is placed)
-----
604102 Teaching Placement-Height
Time-out of [OFF] signal of Linear measure sensor
-----
604103 Teaching Placement-Height
Error in DD-axis
-----
604104 Teaching Placement-Height
Error in NS-axis
-----
604105 Teaching Placement-Height
Error in DD/NS-axis
-----
604106 Teaching Placement-Height
Time-out of DD/NS-axis
-----
604107 Teaching Placement-Height
Error in calculating drive wave of HL-axis
-----
1012-005
4OM-1603
3-138
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604108 Teaching Placement-Height
Error in calculating drive wave of NL-axis
-----
604109 Teaching Placement-Height
Time-out of starting HL/NL-axis movement
-----
60410a Teaching Placement-Height
Time-out of starting HL-axis movement
-----
60410b Teaching Placement-Height
Time-out of starting NL-axis movement
-----
60410c Teaching Placement-Height
T
ime-outofnishingHL/NL-axismovement
-----
60410d
Teaching Placement-Height
Failed in measuring real time of linear measure sensor.
-----
60410e Teaching Placement-Height
ODD Noz is placed on Head, or error is detected during linear measure sensor.
-----
60410f Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(Under 0.2mm)
-----
604110 Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(Over 2.5mm)
-----
604111 Teaching Placement-Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604112 Teaching Placement-Height
Program Error
-----
604113 Teaching Placement-Height
Offset is 1mm less than the set value.
-----
604114 Teaching Placement-Height
Offset is 1mm more than the set value.
-----
604115 Teaching Placement-Height
The value of Flowmeter is higher than 5.0V.
-----
604116 Teaching Placement-Height
The value of Flowmeter is lower than 4.7V.
-----
1012-005
4OM-1603
3-139
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
604117 Teaching Placement-Height
Thereisnomeasureddataof
Noz1.ItisnecessarytomeasureNoz1rst.
-----
604118 Teaching Placement-Height
CannotmeasureitforXY-coord
isnotdened.
-----
604119 Teaching Placement-Height
Error in Flowing Quantity
-----
604201 Chute(For adjustment when shipping up) Teaching Height
Error is detected before starting Detection on Linear Measure Sensor.(There is a
possibility that Linear measure sensor is broken, or Odd Noz is placed.)
-----
604202 Chute(For adjustment when shipping up) Teaching Height
Time-out of [OFF] signal of Linear measure sensor
-----
604203 Chute(For adjustment when shipping up) Teaching Height
Error in DD-axis
-----
604204 Chute(For adjustment when shipping up) Teaching Height
Error in NS-axis
-----
604205 Chute(For adjustment when shipping up) Teaching Height
Error in DD/NS-axis
-----
604206 Chute(For adjustment when shipping up) Teaching Height
Time-out of DD/NS-axis
-----
604207 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of HL-axis
-----
604208 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of NL-axis
-----
604209 Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL/NL-axis movement
-----
60420a Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL-axis movement
-----
60420b Chute(For adjustment when shipping up) Teaching Height
Time-out of starting NL-axis movement
-----
60420c Chute(For adjustment when shipping up) Teaching Height
T
ime-outofnishingHL/NL-axismovement
-----
