4OM-1603

3-128

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

600904 Teaching Leaning Nozzle offset

Error of Data set for XY Beam.

-----

600905 Teaching Leaning Nozzle offset

Error of moving for XY Beam.

-----

600906 Teaching Leaning Nozzle offset

Time-out in XY Beam movement

-----

600907 Teaching Leaning Nozzle offset

Time-out of communication with recognition.

-----

600908 Teaching Leaning Nozzle offset

Error of Leaning Nozzle offset teaching

-----

600909 Teaching Leaning Nozzle offset

-----

60090A Teaching Leaning Nozzle offset

-----

60090B Teaching Leaning Nozzle offset

-----

601001 Master nozzle level offset teach

Error is detected before Line Sensor measurement began

-----

601002 Master nozzle level offset teach

Error of NS-axis movement

-----

601003 Master nozzle level offset teach

Error of DD-axis movement

-----

601004 Master nozzle level offset teach

Time-out of NS-axis movement

-----

601005 Master nozzle level offset teach

Time-out of DD-axis movement

-----

601006 Master nozzle level offset teach

Time-out when Line Sensor measurement began

-----

601007 Master nozzle level offset teach

Read Time-out of Line Sensor measurement

-----

4OM-1603

3-129

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

601101 Noz level offset teaching

Time-out when Line Sensor measurement began

-----

601102 Noz level offset teaching

Read Time-out of Line Sensor measurement

-----

601103 Noz level offset teaching

Error during Line Sensor measurement

-----

601104 Noz level offset teaching

Error of dirty Line Sensor

-----

601105 Noz level offset teaching

Error of NS-axis Origin calculation

-----

601106 Noz level offset teaching

Error of NS-axis movement

-----

601107 Noz level offset teaching

Error of DD-axis Origin Calculation

-----

601108 Noz level offset teaching

Error of DD-axis movement

-----

601109 Noz level offset teaching

Program Error

-----

60110a Noz level offset teaching

Error before Line Sensor measurement began

-----

60110b Noz level offset teaching

Nozzle on Head is not placed

-----

601301 Noz stocker offset teaching

Error of coordinates calculation(XY)

-----

601302 Noz stocker offset teaching

Error of XY-axis movement

-----

601303 Noz stocker offset teaching

Time-out in XY-axis movement

-----

601304 Noz stocker offset teaching

Error of HL-axis movement

-----

4OM-1603

3-130

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

601305 Noz stocker offset teaching

Error of NL-axis movement

-----

601306 Noz stocker offset teaching

Error of L-axis movement

-----

601307 Noz stocker offset teaching

Error of HL/NL/L-axis movement

-----

601308 Noz stocker offset teaching

Nozzle stocker is not clamped

-----

601309 Noz stocker offset teaching

Error of Lighting On of P.C.B. Recognition Camera

-----

60130a Noz stocker offset teaching

Timeout of Lighting On of P.C.B. Recognition Camera

-----

60130b Noz stocker offset teaching

Error of Lighting Off of P.C.B. Recognition Camera

-----

60130c Noz stocker offset teaching

Time-out of Lighting Off of P.C.B. Recognition Camera

-----

60130d Noz stocker offset teaching

Error of image capture of Nozzle Stocker Mark

-----

60130e Noz stocker offset teaching

Time-out of image capture of Nozzle Stocker Mark

-----

60130f Noz stocker offset teaching

Error of Recognition Performance of Nozzle Stocker Mark

-----

601310 Noz stocker offset teaching

Time-out of Recognition Performance of Nozzle Stocker Mark

-----

601311 Noz stocker offset teaching

Error of output-movement of Nozzle Stocker

-----

601401 T

eachingComp.Recog.CameraMagnicationT

each

Time-out of communication with recognition.

Is there Network with Recognition? Please check.

601402 TeachingComp.Recog.CameraMagnicationT

each

Error of Recognition Command response

-----
