4OM-1603
2-24
3. Machine Information : Chap.2
1012-005
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
801101 Nozzlediameterconrmation
The disagreement of the nozzle diameter was detected with the linear measure.
Thereisapossibility
ofthelinearmeasuredirtandthenozzledirt,pleaseconrm
whether a different nozzle has adhered.
-----
801b01 Lightning Surge alarm
Lightning Surge Protector works; Q204.
-----
801b02 Lightning Surge alarm
Lightning Surge Protector works; Q204. Running continue.
-----
801b03 Lightning Surge alarm
Protective Fuse error of lightning Surge Protector. Exchange the fuse.
-----
801c05 Information
Warm start mode was canceled.
-----
801c06 Information
The machine stopped by the automatic stop function.
-----
802001 Alarm for Splicing
The feeder is running short of the component to feed.
Please prepare for Splicing, and remove the cover tape from the storage section.
-----
802101 Feeder Maintenance alarm
The total number of feeder's shots reached a previous notice setting number.
-----
802102 Feeder Maintenance alarm
The feeder adsorption rate decreased and exceeded the previous notice setting
number.
-----
802201 ACV Information
ACV
CheckError.ComponentID
onthefeederisnotsameasonespeciedby
current program.
-----
802202 ACV Information
Device(Rear) Cannot clear Clamp for feeder communication. Please operate it
again later.
-----
802203 ACV Information
Device(Front) Cannot clear Clamp for feeder communication.
Please operate it again later.
-----
4OM-1603
2-25
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
802204 ACV Information
Device(Rear) Cannot clear Clamp for receiving the result of ACV Check Error.
Please operate it again later.
-----
802205 ACV Information
Device(Front) Cannot clear Clamp for receiving the result of ACV Check Error.
Please operate it again later.
-----
802206 ACV Information
Device(Rear) Time-out for receiving the result of ACV Check Error.
Please take out Feeder and then take it in again.
-----
802207 ACV Information
Device(Front) Time-out for receiving the result of ACV Check Error.
Please take out Feeder and then take it in again.
-----
802208 ACV Information
Device(Rear) Time-out of Feeder communication.
Please take out Feeder and then take it in again.
-----
802209 ACV Information
Device(Front) Time-out of Feeder communication.
Please take out Feeder and then take it in again.
-----
802301 Splicing No Check Alarm
The seam passed the detection sensor as unregistered splicing.
Please register the splicing.
-----
802401 Feeder
CoverTapelledupalarm
The
storagesectionofCoverTapelledwasdetected.
Please remove Tape from internal storage section.
-----
802501 Feeder Communication Error
Failed to displaying Operational Panel.
Please put the Cart down, or pull out and insert Feeder.
-----
802502 Feeder Communication Error
The communication processing of Feeder was not done in prescribed time.
-----
802601 Linear measure sensor
To set synchronized counting position of Head(Rear) is failed.
-----
802602 Linear measure sensor
To set synchronized counting position of Head(Front) is failed.
-----
1012-005
4OM-1603
2-26
3. Machine Information : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
802603 Linear measure sensor
To reset DD origin position of Head(Rear) is failed.
-----
802604 Linear measure sensor
To reset DD origin position of Head(Front) is failed.
-----
803028 FAN Stop alarm
Fan rotation error of Control Box. Clean up Fan.
-----
803101 Feeder Feeding Pitch Correction
Auto Correction is executed for Feeder Feeding Pitch is out of position.
-----
809201 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
809301 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
809c01 Motor system error
Communication not establish with Servo Amp (XY Beam).
Check following
1.
Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809c02 Motor system error
Servo Amp parameter error.
1. There is a possibility that Motor Communication Line is
abnormal.
2. Parameter settings Error(0x21E).
809c03 Motor system error
Communication not establish with Servo Amp (Head).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3.
Communication cable.
809d01 Recycleconveyorlled
up
Recycle conveyor became Full. (Rear)
-----
809d02 Recycleconveyorlled
up
Recycle conveyor became Full. (Front)
-----
809e01 Automatic Teaching
Please
skipitbecauseAutomaticmodicationT
eachingisimpossibleinNozzle
position of Rear Head.
-----
1012-005
