4OM-1603
3-18
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
405201 Detecting upper Magazine rack shutter (Front)
the rack shutter opening is detected during upper elevator moving. (Front)
[B15527, B15529,B15531]
Check out the sensor of closing magazine rack shutter (B15527, B15529,
B15531).
405301 Lower magazine positioning error (Front)
Lower magazine positioning error.(Front)[B15526]
ConrmMagazineClamp.
405401 Upper magazine positioning error (Front)
Upper magazine positioning error.(Front)[B15532]
ConrmMagazineClamp.
405501
Shut-off Motor Breaker for Tray (Rear)
Tripped circuit breaker of motor (Front)
Please turn on again after turning off and cancelling
Trip mode.
405601 Shut-off safety relay of Elevator(Lower) (Front)
Cut off safety relay of lower elevator (Front).
Conrmthemaincircuitandsafety
door.
405701 Shut-off safety relay of Elevator (Upper) (Front)
Cut off safety relay of upper elevator (Front).
Conrmthemaincircuitandsafety
door.
405801 Released Elevator unit clamp (Front)
Released elevator unit clamp (Front) [B15426, B15428]
ConrmtheElevatorUnitClampSensor(B15426,
B15428).
405901 Detecting pickup miss cmpnt of Tray Feeder Cart (Front)
Pickup miss components was detected (Front). [B15412]
1.Openthecover.\r\n2.Conrmsuppressor,
DisengagedLatchandremovethe
Pickup miss cmpnt.\r\n3.Close the cover and then Lock it.
405A01 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Front)
Feeder Disengaged Latch is detected [B15412]
1.Openthecover.\r\n2.Conrmsuppressor,
DisengagedLatchandremovethe
Pickup miss cmpnt.\r\n3.Close the cover and then Lock it.
407001 Detecting Head (Rear) nozzle descending
Invalid detection of head (Rear) nozzle descending
Please perform a zeroing.
407101 Detecting Head (Front) nozzle descending
Invalid detection of head (Front) nozzle descending
Please perform a zeroing.
407201 Pass Line detect (Rear)
Invalid detection of Pass line (Rear)
Please perform a zeroing.
407301 Pass Line detect(Front)
Invalid detection of Pass line (Front)
Please perform a zeroing.
T4C3
1012-005
4OM-1603
3-19
3. Error IDs and Remedial Procedures : Chap.3
1012-005
3.2 Data
Error ID Error Name, Description, Cause, and Remedy
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program(PCB recog steps Error.)
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
410306 Pattern Program Error
The error is found in the nozzle candidate number of the conversion pattern
program.
-----
410307 Pattern Program Error
The error is found in the adsorption lane number of the conversion pattern
program.
-----
410401 Data Error
The components library does not exist. Or, data is in loss.
-----
410402 Data Error
Data relating to nozzle does not exist. Or, data is in loss.
-----
410701 Program Error
It was a error setting of the sequence data.
-----
410801 2D bar code data Error
It was a error setting of the sequence data.
-----
410802 2D bar code data Error
Failed in start-up Sequence
-----
410803 2D bar code data Error
The error is found in coordinates calculation.
-----
4OM-1603
3-20
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
410804 2D bar code data Error
Could not continue for Errors.
-----
T4C4
1012-005
