4OM-1603
3-37
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
42340f Error in NA-L2 axis
System Error on NA-L2 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423410 Error in NA-L2 axis
Communication Error on NA-L2 axis
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
423501 Error in NR-L1 axis
Zeroing Error on NR-L1 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423502 Error in NR-L1 axis
Out-of-Control of NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423503 Error in NR-L1 axis
Error in motor power voltage of NR-L1 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423504 Error in NR-L1 axis
STP input on NR-L1 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423505 Error in NR-L1 axis
Over-current in NR-L1 axis
Abnormal
currentinmotoroutputline
wasdetected.Conrmthemotorwiring,
supplying power.
423506 Error in NR-L1 axis
Limit sensor(+) on NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423507 Error in NR-L1 axis
Limit sensor(-) on NR-L1 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423508 Error in NR-L1 axis
Motor disconnection of NR-L1 axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423509 Error in NR-L1 axis
Error in control power voltage of NR-L1 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42350a Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
4OM-1603
3-38
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
42350b Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42350c Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42350d Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42350e Error in NR-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42350f Error in NR-L1 axis
System Error on NR-L1 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423510 Error in NR-L1 axis
Communication Error on NR-L1 axis
1.
Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
423601 Error in NR-L2 axis
Zeroing Error on NR-L2 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423602 Error in NR-L2 axis
Out-of-Control of NR-L2 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
423603 Error in NR-L2 axis
Error in motor power voltage of NR-L2 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423604 Error in NR-L2 axis
STP input on NR-L2 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423605 Error in NR-L2 axis
Over-current in NR-L2 axis
Abnormal
currentinmotoroutputline
wasdetected.Conrmthemotorwiring,
supplying power.
423606 Error in NR-L2 axis
Limit sensor(+) on NR-L2 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
4OM-1603
3-39
3. Error IDs and Remedial Procedures : Chap.3
1012-005
Error ID Error Name, Description, Cause, and Remedy
423607 Error in NR-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
423608 Error in NR-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
423609 Error in NR-L2 axis
System Error on NR-L1 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
42360a Error in NR-L2 axis
Communication Error on NR-L1 axis
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
42360b Error in NR-L2 axis
Zeroing Error on NR-L2 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
42360c Error in NR-L2 axis
Out-of-Control of NR-L2 axis was detected
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
42360d Error in NR-L2 axis
Error in motor power voltage of NR-L2 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
42360e Error in NR-L2 axis
STP input on NR-L2 axis was detected
STP input is detected. The function to stop motor by Hard signal.
42360f Error in NR-L2 axis
Over-current in NR-L2 axis
Abnormal
currentinmotoroutputline
wasdetected.Conrmthemotorwiring,
supplying power.
423610 Error in NR-L2 axis
Communication Error on NR-L2 axis
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
5. ConrmFirmwareofDriver.
424001 Stopper movement Error
Stop sensor was detected before positioning(R) stopper
ThereisapossibilitythatP
.C.B.ispulledandraisedinStopper.Pleaseconrm
P.C.B. stopping position.
