4OM-1603

3-56

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

43180b Tray Feeder in advanced check error (Rear)

No Magazine(Upper)

Please set Magazine(Upper).

43180c Tray Feeder in advanced check error (Rear)

No Magazine(Lower)

Please set Magazine(Lower).

43180e Tray Feeder in advanced check error (Rear)

Traverse axis Servo Alarm

-----

431810 Tray Feeder in advanced check error (Rear)

Elevator axis Servo Alarm

-----

431811 Tray Feeder in advanced check error (Rear)

Miss-Pickup comp. Detection 8mm[B15417]

-----

431812 Tray Feeder in advanced check error (Rear)

Miss-Pickup comp. Detection 14mm[B15418]

-----

431813 Tray Feeder in advanced check error (Rear)

Miss-Pickup comp. Detection 28mm[B15419]

-----

431814 Tray Feeder in advanced check error (Rear)

Pallet chuck is not shut

-----

431815 Tray Feeder in advanced check error (Rear)

The pallet Miss-Set was detected.

-----

431816 Tray Feeder in advanced check error (Rear)

Magazine(Lower) Rack Shutter on the operator side is open.

-----

431817 Tray Feeder in advanced check error (Rear)

Magazine(Lower) Rack Shutter on the side of Traverse is open.

-----

431818 Tray Feeder in advanced check error (Rear)

Magazine(Lower) is not done positioning yet.

Please

conrmtheMagazinepositionand

Magazinelocklever.

431819 Tray Feeder in advanced check error (Rear)

Elevator axis safety relay

-----

43181a Tray Feeder in advanced check error (Rear)

Magazine(Upper) Rack Shutter on the operator side is open.

-----

43181b Tray Feeder in advanced check error (Rear)

Magazine(Upper) Rack Shutter on the Traverse side is open.

-----

4OM-1603

3-57

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

43181c Tray Feeder in advanced check error (Rear)

Magazine(Upper) is not done positioning yet.

PleaseconrmtheMagazinepositionand

Magazinelocklever.

431820 Tray Feeder in advanced check error (Rear)

Zeroing incomplete

-----

434001 Tray Feeder Sequence Error (Rear)

Tray feeder sequence timeout

-----

438302 Elevator Unit exchange (Attach) (Rear)

Elevator unit was not detected.

Please set up Tray Unit in Exchange location.

438303 Elevator Unit exchange (Attach) (Rear)

Connector of Feeder base is not positioned correctly

Please Operate it after connecting connector of Feeder Base.

438304 Elevator Unit exchange (Attach) (Rear)

Connector of Tray is not positioned correctly

Operate it after connecting connector of Tray.

438305 Elevator Unit exchange (Attach) (Rear)

Time-out of Clamp operating of Elevator Unit.

-----

438306 Elevator Unit exchange (Attach) (Rear)

Feeder base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

438402 Elevator Unit exchange (Detach) (Rear)

Time-out of Unclamp operating of Elevator Unit.

-----

438403 Elevator Unit exchange (Detach) (Rear)

Feeder base is not in Upward position.

Please press READY switch on Feeder Base, and rise it after setting Feeder cart..

438501 Multi-Tray (Rear)

Time-out of waiting for initialization

Please

conrmAE-LINKwiringandPower

wiring.

438502 Multi-Tray (Rear)

Can not communicate Driver.

PleaseconrmAE-LINKwiringandPower

wiring.

438503 Multi-Tray (Rear)

Communication Status Error(Stand by)

PleaseconrmAE-LINKwiringandPower

wiring.

438504 Multi-Tray (Rear)

Communication Status Error(Alarm)

PleaseconrmAE-LINKwiringandPower

wiring.

438505 Multi-Tray (Rear)

Communication Status Error(OT)

PleaseconrmAE-LINKwiringandPower

wiring.

4OM-1603

3-58

3. Error IDs and Remedial Procedures : Chap.3

1012-005

Error ID Error Name, Description, Cause, and Remedy

438506 Multi-Tray (Rear)

Communication Status Error(Connection O)

PleaseconrmAE-LINKwiringandPower

wiring.

438507 Multi-Tray (Rear)

Communication Status Error(Driver Alarm)

PleaseconrmAE-LINKwiringandPower

wiring.

438508 Multi-Tray (Rear)

Communication Status Error(SV-net stopping)

PleaseconrmAE-LINKwiringandPower

wiring.

438509 Multi-Tray (Rear)

Communication Status Error(Out of Connection number)

PleaseconrmAE-LINKwiringandPower

wiring.

43850A Multi-Tray (Rear)

Communication Status Error(SV-VET Error)

PleaseconrmAE-LINKwiringandPower

wiring.

43850B Multi-Tray (Rear)

Failed to read the number of Axes

PleaseconrmAE-LINKwiringandPower

wiring.

43850C Multi-Tray (Rear)

Driver-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

43850D Multi-Tray (Rear)

Elevator1-axis is not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

43850E Multi-Tray (Rear)

Elevator2-aixs in not connected.

PleaseconrmAE-LINKwiringandPower

wiring.

438510 Multi-Tray (Rear)

Motor Breaker Trip Error

-----

438511 Multi-Tray (Rear)

Elevator Unit is not connected.

Please connect Elevator unit in Unit exchange menu.

438512 Multi-Tray (Rear)

All connectors of Elevator Unit are not connected.

Pleaseconrmtheconnectiontoall

connectorofElevatorUnit

438513 Multi-Tray (Rear)

Failed to start-up Communication of SV-NET.

PleaseconrmAE-LINKwiringandPower

wiring.

438514 Multi-Tray (Rear)

Failed to turn on Multi-tray.(Time-out)

-----

438515 Multi-Tray (Rear)

(AtnishingAutoRun)Multi-trayoperation

isnotcompletedwithinaspecied

time.

Please push Emergency Stop button.
