4OM-1603
3-111
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3405 Nozzle check Error before Pickup(Detected before operating)
Error in discarding the remains detect component
-----
4b3406 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up(program error)
-----
4b3501 Automatic Zeroing Error
Failed to zeroing automatically
Please restart.
4b3601 Receding Error
Motor Error on receding
-----
4b3602 Receding Error
Time-out on receding
-----
4b3701 Writing Origin position of License nozzle
Linear measure Sensor error is detected before operating.
-----
4b3702 Writing Origin position of License nozzle
Failed in getting Offset data
-----
4b3703 Writing Origin position of License nozzle
Failing in writing origin position of Noz.
-----
4b3801 Bad Mark Sensor Error
Cannot detect Bad Mark normally for Error in Bad Mark Sensor.
Execute adjustment of Bad Mark Sensor
4b3901 Bad Mark Sensor Adj Error
Failed to recog the white of Bad Mark.
-----
4b3902 Bad Mark Sensor Adj Error
Bad Mark Sensor Error, Stability signal is not off.
-----
4b3903 Bad Mark Sensor Adj Error
Bad Mark Sensor Error, Stability signal is not off.
-----
4b3904 Bad Mark Sensor Adj Error
Failed to recog the Black of Bad Mark.
-----
4b3905 Bad Mark Sensor Adj Error
Condition
Error.Pleaseadjustthe
whileofBadMarkrst.
-----
4b3906 Bad Mark Sensor Adj Error
Failed in Level retreat.
-----
1012-005
4OM-1603
3-112
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3907 Bad Mark Sensor Adj Error
Time-out of head moving.
-----
4b3908 Bad Mark Sensor Adj Error
-----
-----
4b3909 Bad Mark Sensor Adj Error
-----
-----
4b390a Bad Mark Sensor Adj Error
-----
-----
4b390b Bad Mark Sensor Adj Error
Parameter Error
-----
4b4001 Damaged cover tape / Cover tape jammed in the storage / Splicing section
peeling off
Alarm Code:E0 - (1)Damaged cover tape/ (2)Cover tape jammed in the storage/
(3)Splicing section peeling off
(1)
Conrmwhetherornotthe
covertapeissetcorrectly
(2) Please remove the cover tape from the storage section.
(3) Please check the splicing condition if the work performed correctly in the
process.
4b4101 Cover tape peeling off error (Get caught up)
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
(1)Conrmwhetherornotthe
covertapeissetcorrectly.
(2)Conrmwhetherornotsomestickymaterialhasadheredtothesuppressor.
(3)Conrmthesplicingconditioniftheworkperformedcorrectlyintheprocess.
4b4201 Feeder Alarm
Alarm Code:E2 - Origin Position Checking Error
(Excessively out of the origin during servo ON)
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4202 Feeder Alarm
Alarm Code:E4 - Positioning Completion Timeout
(Foreign substances in the sprocket wheel)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
4b4203 Feeder Alarm
Alarm Code:E6 - Lane Change Timeout Error
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
1012-005
4OM-1603
3-113
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b4204 Feeder Alarm
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4205 Feeder Alarm
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Conrmwhetherornotthetape
isbeingjammedonthepath.
Conrmthereeltooperatesmoothly.
Conrmwhetherornotsomecomponentsanddustarebeingcaughtinthe
sprocket.
Conrmwhetherornotsomecomponents
anddustarebeingcaughtinthetape
feeding gear.
4b4301 Feeder Section(Miss-pickup)
A pickup error occurred due to feeder operation problem.
Please check the feeder and the component.
-----
4b4401 ErrorinconrmingconnectionofFeeder
Error
inconrmingconnectionofFeeder
Please check connection of Feeder
4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b4601 Feeder error (feeding time-out)
Feeder error (feeding time-out)
-----
4b4701 SV-NET Communication
Internal Error.
Please restart the machine.
4b4801 2D bar code Time-out
Time-out of Sequence
-----
4b4802 2D bar code Time-out
Time-out of Communication
-----
4b4901 Feeder Feeding Pitch Correction Error
Feeder Feeding Pitch is out of position, but Auto Correction for it failed.
Please do teaching pick-up position.
4b4a01 Recycle Conveyor is taken off.
Do not take off Recycle Conveyor, please.
-----
4b4a02 Recycle Conveyor is taken off.
There is a possibility that Noz bent. Do not take off Recycle Conveyor during
Disposal.
Please
opentheCover,then
conrmwhetherNozdidnotbend.
