4OM-1603
3-84
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49611a Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49611b Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49611c Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49611d Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49611e Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49611f Conveyor Width W1 Error
System Error in Conveyor Width W1.
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
496120 Conveyor Width W1 Error
Communication Error in Conveyor Width W1.
1.
Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496201 Conveyor Width W2 Error
Drive Alarm during Conveyor Width W2 axial operation.
ConrmresetMethodofdetailedSub-system
errorcountsofAlarm.
496202 Conveyor Width W2 Error
Conveyor Width W2-axis could not start
A state in which the operating command is not normally accepted.
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496210 Conveyor Width W2 Error
System setup of Conveyor Width W2 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
496211 Conveyor Width W2 Error
Zeroing Error in Conveyor Width W2
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
1012-005
4OM-1603
3-85
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
496212 Conveyor Width W2 Error
Out-of-Control in Conveyor Width W2
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496213 Conveyor Width W2 Error
Error in Motor Power voltage of Conveyor Width W2
Motor power voltage dropped. Check out the Power supply line(48V Line)
496214 Conveyor Width W2 Error
STP input in Conveyor Width W2 was detected
STP input is detected. The function to stop motor by Hard signal.
496215 Conveyor Width W2 Error
Over-current in Conveyor Width W2
Error in Motor output line. Check out the motor wiring,
496216 Conveyor Width W2 Error
Limit Sensor(+) was detected in Conveyor Width W2.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496217 Conveyor Width W2 Error
Limit Sensor(-) was detected in Conveyor Width W2.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496218 Conveyor Width W2 Error
Motor Disconnection of Conveyor Width W2 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496219 Conveyor Width W2 Error
Control Power Voltage of Conveyor Width W2 has an error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49621a Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621b Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621c Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621d Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621e Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
1012-005
4OM-1603
3-86
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
49621f Conveyor Width W2 Error
System Error in Conveyor Width W2.
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
496220 Conveyor Width W2 Error
Communication Error in Conveyor Width W2.
1. Conrmconnectiontocommunicationcable.
2. Conrm
Powersupply(24V).
3. ConrmthecommunicationsettingofPCIboard.
4. Conrmtheaddressofdriverandcommunicationratesetting.
496310 Error of Shuttle Conveyor width W1 in Input side
System setup of Conveyor Width W1 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a
correct setup has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
496311 Error of Shuttle Conveyor width W1 in Input side
Zeroing Error in Conveyor Width W1
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
496312 Error of Shuttle Conveyor width W1 in Input side
Out-of-Control in Conveyor Width W1
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred.
Please execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure
motor Error.
496313 Error of Shuttle Conveyor width W1 in Input side
Error in Motor Power voltage of Conveyor Width W1
Motor power voltage dropped. Check out the Power supply line(48V Line)
496314 Error of Shuttle Conveyor width W1 in Input side
STP input in Conveyor Width W1 was detected
STP input is detected. The function to stop motor by Hard signal.
496315 Error of Shuttle Conveyor width W1 in Input side
Over-current in Conveyor Width W1
Error in Motor output line. Check out the motor wiring,
496316 Error of Shuttle Conveyor width W1 in Input side
Limit Sensor(+) was detected in Conveyor Width W1.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
496317 Error of Shuttle Conveyor width W1 in Input side
Limit Sensor(-) was detected in Conveyor Width W1.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496318 Error of Shuttle Conveyor width W1 in Input side
Motor Disconnection of Conveyor Width W1 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
