4OM-1603 4-1 1 3. Recognition Error IDs and Remedial Procedures : Chap.4 1012-005 Recognition Error ID Description of Recognition Error 06801 102 Base mark not found in recognizable range. 06801201 Extensive error in sim…
4OM-1603
4-10
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
05b00002 The pick-up position has deviated greatly in X direction.
05b00003 The pick-up position has deviated greatly in Y direction.
05b00004 The pick angular skew is big.
05b00000 Others.
05e00000 Others.
15000000 Others.
06001001 Base mark not found in recognizable range.
06001002 The position of base mark slips off.
06001101 The Base mark is not found, because light turn off.
06001102 Base mark not Acquiring in recognizable range.
06001201 The Base mark is not found, because mark light too bright.
06001202 Base mark not Acquiring in recognizable range.
06000001 Specied
marknotfoundinrecognizable
range.
06000101 The Base mark is not found, because mark light turn off.
06000102 The Base mark is not found, because too dark.
06000201 Base mark not found in recognizable range. Because mark light turn on.
06000202 The Base mark is not found, because too bright.
06000000 Others.
06101001 Base mark not found in recognizable range.
06100001 Speciedmarknotfoundinrecognizable
range.
06100000 Others.
06201001 Base mark not found in recognizable range.
06201100 Base mark edge not detected.
06201201 Base mark edge not detected.
06201401 Base mark corner not detected.
06201402 Base mark corner not detected.
06201403 Base mark corner not detected.
06201404 Base mark corner not detected.
06201405 Base mark corner not detected.
06200001 Specied
marknotfoundinrecognizable
range.
06200100 Edge not detected.
06200201 Edge not detected.
06200401 Corner not detected.
06200402 Corner not detected.
06200403 Corner not detected.
06200404 Corner not detected.
06200405 Corner not detected.
06200000 Others.
06301101 Base Mark shape not circle.
06301102 Base Mark shape not square.
06301201 Base mark edge not detected.
06300101 Specied
markisnotcircle.
06300102 Speciedmark
isnotsquare.
06300201 Edge not detected.
06300000 Others.
06801
101 Base mark not found in recognizable range.
4OM-1603
4-11
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
06801102 Base mark not found in recognizable range.
06801201 Extensive error in similitude of mark size.
06801202 Extensive error in similitude of mark size.
06801301 Extensive error in similitude of mark shape.
06801302 Extensive error in similitude of mark shape.
06801401 Extensive error in similitude of mark shape.
06801402 Extensive error in similitude of mark shape.
06801501 Base mark not found in recognizable range.
06801502 Base mark not found in recognizable range.
06801601 Base mark not found in recognizable range.
06801602 Base mark not found in recognizable range.
06801603 Base mark not found in recognizable range.
06801604 Base mark not found in recognizable range.
06800101 Specied
marknotfoundinrecognizable
range.
06800102 Speciedmarknotfoundinrecognizable
range.
06800201 Extensive error in similitude of mark size
06800202 Extensive error in similitude of mark size
06800301 Extensive error in similitude of mark shape
06800302 Extensive error in similitude of mark shape
06800401 Extensive error in similitude of mark shape
06800402 Extensive error in similitude of mark shape
06800501 Speciedmarknotfoundinrecognizable
range.
06800502 Speciedmarknotfoundinrecognizable
range.
06800601 Speciedmarknotfoundinrecognizable
range.
06800602 Speciedmarknotfoundinrecognizable
range.
06800603 Speciedmarknotfoundinrecognizable
range.
06800604 Speciedmarknotfoundinrecognizable
range.
06800000 Others.
06e00001 Others.
06e00000 Others.
16000000 Others.
07000001 Nozzle not detected.
07000000 Others.
07100001 Nozzle not detected.
07100000 Others.
07200001 Nozzle not detected.
07200002 Nozzle not detected.
07200000 Others.
07300101 Edge not detected.
07300102 Nozzle not detected.
07300111 Nozzle not detected.
07300112 Nozzle not detected.
07300113 Nozzle not detected.
07300114 Nozzle not detected.
07300000 Others.
07800101 Nozzle size has exceeded the allowable range.
4OM-1603
4-12
3. Recognition Error IDs and Remedial Procedures : Chap.4
1012-005
Recognition Error ID Description of Recognition Error
07800102 Nozzle size has exceeded the allowable range.
07800201 Check error
07800202 Check error
07800301 Nozzle position has exceeded the allowable range.
07800302 Nozzle position has exceeded the allowable range.
07800303 Nozzle position has exceeded the allowable range.
07800304 Nozzle position has exceeded the allowable range.
07800401 Nozzle size has exceeded the allowable range.
07800402 Nozzle size has exceeded the allowable range.
07800403 Nozzle position has exceeded the allowable range.
07800000 Others.
07900000 Others.
07e00001 Others.
07e00000 Others.
17000000 Others.
08000001 The nozzle is not stored.
08100001 The locator mark cannot be detected.
08100000 Others.
08200001 There are characters that cannot be detected.
08200000 Others.
08300000 Others.
08800000 Others.
08900000 Others.
08e00000 Others.
08000000 Others.
18000000 Others.
09000000 Others.
09000001 The detection result cannot judge the bad mark existence because of the vicinity
of the boundary value.
09100000 Others.
09100001 There is spots in the bad mark inspection area.
09e00000 Others.
19000000 Others.
0a000000 Lighting teaching Error
0a000001 Lighting teaching Error
0a000002 Lighting teaching Error
0a000003 Lighting teaching Error
0a000004 Lighting teaching Error
0a000010 The front reverse side of the Jig is opposite
0a000011 Jig is not placed.
0a000012 The contrary or Jig are not placed for the front reverse side of Jig.
0a000013 Lighting teaching Error
0a000014 Jig is not correct.
0a000020 Lighting teaching Error
0a000030 Lighting teaching Error
0a000031 Lighting teaching Error
