Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.2 BOARD
Version
01
Title
Sign of board malfunctions
Page
3-2-4
Note
Classification
Head
AMP
Board
Axis
IO
Board
SBC
Board
NT
A8
Board
Back
Plane
Board
Vision
IF
Board
Feeder
IO
Board
CAN
Conveyor
Board
Head Z,R axis
noises, vibration,
shaking, and so on.
O O
"Alarm detected on
head axis" error
occurs.
O O
Homing error on a
head axis.
O O
"Alarm detected on
head axis" error
occurs.
O O
Head Homing not
allowed.
O O
Head's axial motor
or homing location
is changed” error
occurs.
O O
No signal on the
monitor during
power on.
O O
Blue screen during
booting or
operation.
O O
While loading the
MMI
"Grabber type does
not match…" "fail
to run visframe"
"Run Time Error"
error
O
MMI or PC down
during MMI
operation.
O O
PC booting repeats. O O
MMI downloading
stopped.
O O
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.2 BOARD
Version
01
Title
Sign of board malfunctions
Page
3-2-5
Note
Classification
Head
AMP
Board
Axis
IO
Board
SBC
Board
NT
A8
Board
Back
Plane
Board
Vision
IF
Board
Feeder
IO
Board
CAN
Conveyor
Board
Cannot boot due to
HDD detection
error.
O
PC processing speed
slow and freezing
up.
O O
While loading the
MMI
Initializing
Machine I/F...
errors.
O O O O
"Assert Fail" errors. O
Monitor video off
(intermittent)
decolorization,
screen shaking.
O
MFC related
arithmetic error
when booting the
MMI. (Not Found
System)
O
Pick up error O O O
Failed to detect a
part.
O
Gantry Mounting
Offset off.
O
Optimizer execution
paused.
O
Forcefully
terminating the
MMI after running
the Optimizer.
O
PCB File
Downloading fails.
O
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.2 BOARD
Version
01
Title
Sign of board malfunctions
Page
3-2-6
Note
Classification
Head
AMP
Board
Axis
IO
Board
SBC
Board
NT
A8
Board
Back
Plane
Board
Vision
IF
Board
Feeder
IO
Board
CAN
Conveyor
Board
Bad Mark detection
range exceeded.
O
Pause during
production.
O O
Fly camera video
not displayed. Video
off. Noises.
O O
Time out error while
processing the
vision command.
O O
Fiducial Camera
noises (video off,
half screen,
overlapping screen).
O
"PCB fiducial mark
detection failed"
error occurs.
O
Camera Detection
Time Out Error
(vision
communication
error)
O O
Fix Camera lighting
bad.
O
Monitor video
shaking.
O
X-axis noises. O
Y-axis noises. O
X-axis does not
operate.
O
