Model DECAN Series Company SAMSUNG TECHWIN Module 3.12 MMI V ersion 01 Tit le MMI VERSION CHECK Page 3-12-23 Note [MMI VERSION CHECK] 1. In the bottom left corner of the MMI, click on the C/M icon to check the version. 2…
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.12 MMI
Version
01
Title
LIGHT CHECK
Page
3-12-22
Note
Check if the Fly Camera 1~10's brightness is changed.
Adjust the Outer & Side lighting values to visually check if the brightness is changed.
(Outer lighting is hard to check visually so use a mirror to check it.)
In the Vision windows, check if the output is normal.
There should be no noise, screen shaking/distortion or missing outputs.
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.12 MMI
Version
01
Title
MMI VERSION CHECK
Page
3-12-23
Note
[MMI VERSION CHECK]
1. In the bottom left corner of the MMI, click on the C/M icon to check the version.
2. You can check the Optimizer version in two different ways.
Run the SMARTSM\BIN\SOpti.exe program to check.
MMI => Enter MARKFAC => Enter Password => Enter F4 Option F10 Sys.Print to check the version.
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.12 MMI
Version
01
Title
MMI Installation
Page
3-12-24
Note
[MMI Installation]
1. Run the MMI installation file, and click on <Next>.
2. After selecting an item suitable for the equipment function, click on <Next>.
