Model DECAN Series Company SAMSUNG TECHWIN Module 3.1 1 HEAD V ersion 01 Tit le HEAD AMP ASSEMBL Y (F2) Page 3-1 1-21 Note *Connector not connected
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
HEAD AMP ASSEMBLY (F2)
Page
3-11-20
Note
*Tie fixing
*Connect the Connector and the Ground Cable.
*Connect the H1H6-VAC, H7H10-VAC Cable to the Flat Cable and the fix them to the board.
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
HEAD AMP ASSEMBLY (F2)
Page
3-11-21
Note
*Connector not connected
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.11 HEAD
Version
01
Title
HEAD AMP ASSEMBLY (L2)
Page
3-11-22
Note
[HEAD AMP ASSEMBLY (L2)]
Head AMP Assembly
Head AMP wiring
