Model DECAN Series Company SAMSUNG TECHWIN Module 3.14 OS V ersion 01 Tit le HDD RECOVERY(OS SETUP) Page 3-14-6 Note 10. Press < Next> and click on <OK>. 11. When recovery is finished, click on <OK> to …
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.14 OS
Version
01
Title
HDD RECOVERY(OS SETUP)
Page
3-14-5
Note
5. Press <Next> and click on <OK>.
6. When recovery is finished, click on <OK>.
7. Separate the external HDD and USB from the PC and reboot the PC.
8. When the booting continues to the Recovery Zone, press the <Enter> key.
9. Press the [F3] key to restore the initial condition.
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.14 OS
Version
01
Title
HDD RECOVERY(OS SETUP)
Page
3-14-6
Note
10. Press <Next> and click on <OK>.
11. When recovery is finished, click on <OK> to finish.
12. Reboot the PC and check the driver installation in Device Manager.
13. Set the windows time and date.
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.14 OS
Version
01
Title
EQUIPMENT/LAPTOP CONNECTION TO
NETWORK
Page
3-14-7
Note
[EQUIPMENT/LAPTOP CONNECTION TO NETWORK]
1. Connect the LAN cable to the LAN port of the laptop and the equipment rear.
2. In the Windows <Background>, right click with your mouse button on the <Network Environment> menu
and click on <Properties>.
3. Select <Local Network>,right click with your mouse button and click on <Properties>.
4. Select <TCP/IP> and click on the <Property> button.
