1OM-1610 3-36 5. Running-In Operation : Chap.3 091 1-001
1OM-1610
3-35
5. Running-In Operation : Chap.3
(5) Press the [MODE SET] button. The "MODE SET" window opens.
1
Select the pattern
3
Determine the pattern
2
Select the operation
F1C34
(6) Select one of the pattern buttons for a test run on running-in operation and
press the [APPLY] button. (Example: [Pattem #3] Button) "TEST RUN: #
(Pattern No.)" appears beside the current status of each stage in the "Status
Indicator" eld located at the upper area of the window.
(7) To use the specied test mode stop function, it is required to set up the
specic time after pressing the [Specied time] button in the "Stop at
specied time of test mode" group box.
(8) Press the [START] button on the operation panel.
The running-in operation starts.
(9) To stop the running-in operation, press the [STOP] button on the operation
panel.
(10) To exit from the test mode, press the [DISABLE] and
the [APPLY] buttons
in the "MODE SET" window. "TEST
RUN: # (Pattern No.)" disappears from
the "Status Indicator" eld located at the upper area of the window and the
normal mode resumes.
0911-001
1OM-1610
3-36
5. Running-In Operation : Chap.3
0911-001
1OM-1610
0911-001 4-A
Chapter 4
Program Change Operation
In this chapter, the pattern program change procedure is described.
1. Outline of Program Change Operation
2. Preparation for Program Change Operation
3. Program Change Operation
4. ConrmationofPlacement
